Nylon, also known as polyamide in Chinese, is a general term for thermoplastic resins with repeated amide groups - [NHCO] - on the main chain of the molecule. Its naming is determined by the specific number of carbon atoms in the synthetic monomer. It was invented by the American chemical industry giant DuPont chemist Carothers and his research team.
The nylon series is an important engineering plastic. This product is widely used, covering almost every field, and is one of the most widely used varieties among the five major engineering plastics.
1: Nylon 6 (white): This material has excellent comprehensive properties, including mechanical strength, rigidity, toughness, mechanical shock absorption, and wear resistance. These characteristics, combined with good electrical insulation and chemical resistance, make Nylon 6 a "general-purpose" material for the manufacture of mechanical structural parts and maintainable parts.
2: Nylon 66 (cream): Compared to Nylon 6, it has better mechanical strength, rigidity, heat resistance, and wear resistance, but lower impact strength and mechanical shock absorption, making it very suitable for automatic lathe machining.
3: Nylon 4.6 (reddish-brown): Compared to ordinary nylon, Nylon 4.6 has the characteristics of strong rigidity retention, good creep resistance, better heat aging in a wider temperature range. Therefore, Nylon 4.6 is used for "higher temperature fields" (80 - 150 ℃) where Nylon 6, Nylon 66, POM, and PET do not meet the requirements in terms of rigidity, creep resistance, heat aging, fatigue strength, and wear resistance.
4: Nylon 66+GF30 (black): Compared to pure Nylon 66, this nylon with 30% glass fiber reinforcement has improved heat resistance, strength, rigidity, creep resistance, dimensional stability, and wear resistance, with a higher maximum operating temperature.
5: Nylon 66+MOS2 (gray-black): This nylon filled with molybdenum disulfide has improved rigidity, hardness, and dimensional stability compared to Nylon 66, but with a decrease in impact strength. The formation of molybdenum disulfide crystals improves the crystalline structure, enhancing the material's load-bearing and wear resistance.
Monomer casting nylon plates, also known as MC nylon: English name Monomer casting nylon, Chinese name monomer casting nylon. "Replacing steel with plastic, excellent performance," extremely versatile. It has a variety of unique properties such as light weight, high strength, self-lubrication, wear resistance, corrosion resistance, and insulation. It is a widely used engineering plastic that is almost ubiquitous in all industrial fields.
Main Characteristics of Nylon Plates
High mechanical strength, rigidity, hardness, toughness, good aging resistance, good mechanical shock absorption, good sliding properties, excellent wear resistance, good machinability, effective control when used for precision, no creep phenomenon, good abrasion resistance, good dimensional stability.
Application Fields of Nylon Plates:
Widely used in chemical machinery, anti-corrosion equipment for manufacturing gears and parts, wear-resistant parts, transmission structural parts, household appliance parts, automobile manufacturing parts, screw anti-loose mechanical parts, chemical machinery parts, chemical equipment, etc.
