II. Vertical sewage pump product features
1. Safe and reliable, reducing maintenance costs: The rotor components that have been balanced and the reasonable arrangement of bearings effectively balance the radial and axial forces of the pump, ensuring long-term stable operation of the unit, with low vibration and noise.
2. Strong flow capacity: Smooth large channels, special impeller anti-blocking design, ensure efficient and unclogged pump operation.
3. Double seals, double protection: Two sets of mechanical seals in series configuration, truly achieve double protection, ensuring the safety of the motor.
III. Vertical sewage pump operating conditions
Flow rate: 2-1500 m3/h
Head range: 3-45m
Rated speed n: 970-2900r/min
Medium temperature: -15°C to +60°C
Medium density: ≤1.3×103kg/m3
Medium pH value: 5-9
System maximum working pressure: ≤0.6Mpa
IV. Vertical sewage pump structural diagram
| Number | Component name | Number | Component name |
|
| 1 | Base | 5 | Motor | |
| 2 | Pump body | 6 | Main shaft | |
| 3 | Impeller | 7 | Mechanical seal | |
| 4 | Oil chamber | 8 | Impeller nut |
Five. Vertical sewage pump product uses
Vertical sewage pump is suitable for the discharge of heavily polluted wastewater in factories and commercial areas, sewage pumping stations in residential areas, water distribution systems in urban sewage treatment plants, drainage stations in civil air defense systems, water supply equipment in waterworks, sewage discharge in hospitals and hotels, municipal engineering construction sites, supporting machines in mines, rural biogas digesters, agricultural irrigation and other industries, transporting sewage with particles and debris, can also be used for clean water and weakly corrosive media.
