3、ZX Self-Priming PumpStructural Diagram
|
Serial Number
|
Component Name
|
Serial Number
|
Component Name
|
|
|
1
|
Inlet Pipe
|
5
|
Impeller
|
|
|
2
|
Inlet Check Valve
|
6
|
Mechanical Seal
|
|
|
3
|
Outlet Pipe
|
7
|
Bearing Seat
|
|
|
4
|
Pump Body
|
8
|
Pump Shaft
|
Horizontal Self-Priming Centrifugal Pump Model Significance
