The PLA polylactic acid fully degradable foam sheet production line adopts a high-foaming sheet process with dual-machine series connection, using environmentally friendly CO2 as the foaming agent. It is independently developed and manufactured by our company, holding multiple invention and utility model patents. Tongjia Machinery has now formed a series of equipment models for producing PLA fully degradable foam sheets, including specialized machinery products in three specifications: TJPLA65/90, TJPLA100/130, TJPLA135/150, and TJPLA75/150, with a production capacity ranging from 100kg to 300kg per hour, product width from 600mm to 1200mm, product thickness from 0.5mm to 8mm, and a foaming ratio of 20 to 30 times...
| Machine model | TJ-PLA65/90 | TJ-PLA100/130 | TJ-PLA135/150 | TJ-PLA75/150 | |
| Extruder | Ø65/Ø90 | Ø100/Ø130 | Ø135/Ø150 | Ø75 pairs/Ø150 | |
| Foaming ratio | 5-18 | 5-30 | 5-40 | 5-40 | |
| Product width | mm | 300-640 | 640-1250 | 640-1250 | 640-1250 |
| Cutting method | Single and double cutter | ||||
| Product thickness | mm | 1.0-2 | 1.0-3.5 | 1.0-5.0 | 1.0-5.5 |
| Cooling method | air cooling, water coolingCooled by wind and water | ||||
| Production capacity (approx.) | Kg/h | 60-80 | 150-200 | 180-300 | 250-400 |
| Installed capacity (approx.) | kw | 100 | 200 | 260 | 300 |
| Overall dimensions (approx.) | m | 20×8×2.8 | 23×9×3 | 25×10×3.2 | 25×9×3.2 |
| Machine weight (approx.) | t | 10 | 15 | 18 | 19 |
