Sandon Plastic Products Co., Ltd., our company has long been supplying: imported PET sheet rods,
PET sheet also known as: polyethylene terephthalate material performance parameter table
Product name: PET also known as: polyethylene terephthalate Manufacturer: Germany Gaier Company Sheet: Thickness (10~ 250㎜) * Width 1000㎜ * Length 1000㎜ Rod: ￠10~ ￠80㎜ * 1000㎜ Use: high-load sliding bearing components, pump components, shells, container plugs, embedded gears, electronic industry insulation components, fiber textile industry steering wheels. Features: hard, good stiffness, high strength, toughness, low friction coefficient, high dimensional stability. Its operating temperature is between -40℃ and approximately +110℃. High creep strength, high surface strength, good polishability, high dimensional stability, good sliding performance and wear resistance, good electrical insulation, easy to paint. Disadvantages: general dielectric properties, affected by hydrolysis.
Germany Gaier PET sheet rod, Germany Enxing PET sheet rod, Japan PET sheet rod, USA DuPont PET sheet rod, Switzerland PET sheet rod, high temperature resistant PET sheet rod, Shenzhen PET rod/sheet, Dongguan PET rod/sheet, Guangzhou PET sheet rod, Huizhou PET rod/sheet, Ningbo PET rod/sheet, Shanghai PET rod/sheet, Hunan PET rod/sheet, Hubei PET rod/sheet, Beijing PET sheet rod, Dongguan PET sheet rod, Heilongjiang PET rod/sheet, Sichuan PET rod/sheet, Foshan-PET rod/sheet, Zhongshan Huoju Development Zone-PET rod/sheet, Zhongshan Xiaolan PET rod/sheet, Shenzhen Longhua PET rod/sheet, Dongguan Zhangmutou PET rod/sheet, Dongguan Changping PET sheet rod, Dongguan Dalingshan PET sheet, black PET sheet rod, milk white PET sheet rod, gray PET sheet rod, transparent PET thin sheet, small size PET rod/sheet, ----- sufficient supply, factory direct sales.
Performance parameter table
Property Test standard Data Property Test standard Data
Density ISO1183 1.34g/cm3 Volume resistivity VD0303 ≥1014
Water absorption DIN53495 0.02% Surface resistivity VDE0303 ﹣
Chemical resistance ﹣ Dielectric constant 1MHz DIN53483 3.2
Continuous use temperature ﹣40~ 110℃ Dielectric loss factor 1MHz DIN53483 0.021
Yield tensile strength ISO527 ﹣ Dielectric strength VDE0303 60kv/mm
Yield tensile strain ISO527 ﹣ Leakage current strength DIN5340 KC350
Ultimate tensile strength ISO527 81MPa Bondability ﹢
Ultimate tensile strain ISO527 70% Non-toxic and harmless EEC90/128 ﹣
Impact toughness ISO179 0.B.kJ/m2 Friction coefficient DIN53375 0.25
Notched impact toughness ISO179 ﹣ Flammability UL94 HB
Rockwell ball pressure hardness ISO2039-1 145MPa UV resistance U.V ﹣
Shore D hardness DIN53505 88 Acid resistance ﹢
Bending strength ISO178 ﹣ Alkali resistance 0
Elastic modulus ISO527 2800Mpa Carbonated water resistance
﹢
Vicat softening temperature ISO306 ﹣ Chlorinated carbonate water resistance(CKW) 0
Heat distortion temperature ISO75 170℃ Aromatic compound resistance
﹢
Thermal linear expansion coefficient DIN53752 0.8K-1*104 Ketone resistance ﹢
