The entire machine is equipped with full computerized intelligent PLC control, featuring flexible parameter adjustment, data calculation and monitoring, one-click storage of production parameters, closed-loop feedback for alarms, and integrated intelligent control functions. It uses full servo drive control, which results in low noise, low energy consumption, high output, green energy saving, and high-quality and efficient plasticization. Optional intelligent robot operation is available, fully supporting 5G remote control technology, truly realizing unmanned factory workshop monitoring.
| Machine Model | TJ-RCX500A/TJ-RCX500B | TJ-RCX550A/TJ-RCX550B | TJ-RCX750A/TJ-RCX750B | TJ-RCX850A/TJ-RCX850B | TJ-RCX800A/TJ-RCX800B |
| Overall dimensions | 650cm×130cm×200cm | 950cm×160cm×240cm | 1000cm×160cm×260cm | 1100cm×180cm×260cm | 1100cm×180cm×260cm |
| Maximum molding area | 570mm×450mm | 630mm×500mm | 780mm×700mm | 960mm×800mm | 710mm×800mm |
| Maximum molding width | 610mm | 660mm | 810mm | 980mm | 710mm |
| Maximum molding depth | 80mm | 150mm | 150mm | 150mm | 150mm |
| Sheet thickness | 0.12-2.0mm | 0.12-2.0mm | 0.12-2.0mm | 0.12-2.0mm | 0.12-2.0mm |
| Punching form | Mold Moving Punching | ||||
| Molding Station | continuous three-station, continuous four-station | ||||
| Mold Configuration | General blister aluminum film positive and negative pressure forming mold | ||||
| Total machine power | 60Kw | 75Kw | 120Kw | 205Kw | 115Kw |
| Working air pressure | 0.6-0.8mpa | 0.8mpa | 0.8mpa | 0.8mpa | 0.8mpa |
| Production speed | 15-40 molds/minute | ||||
| Machine weight (approx.) | 3 | 7.5 | 19 | 22 | 15 |
