PTFE Seamless Belt, also known as seamless fusing machine belt, is made of high-strength glass fiber yarn and Kevlar (aramid) woven into a tubular fabric using circular knitting equipment, and is coated with PTFE resin using a unique process.

Features of the seamless belt:

1. The seamless belt, being coated with PTFE, retains the properties of PTFE, exhibiting high-temperature resistance and non-stick characteristics;

2. Compared to conventional fusing machine belts with seams, it overcomes the problem of belt joints easily breaking;

3. The seamless belt eliminates instability and deviation issues caused by unequal circumference at the joints.

4. The surface is smooth and delicate, making it better for processing ultra-thin adhesive interlinings; it has better bending fatigue resistance and durability.

5. The operating life of the seamless fusing machine belt is more than three times longer than that of any seam type PTFE conveyor belt.

The seamless belt is widely used in machinery for tape-based pressing and bonding of interlinings, commonly referred to as fusing machines.

Main application areas of the seamless belt:

△ Widely used in machinery for tape-based pressing and bonding of interlinings.

△ Various food baking and thawing processes (rice, rice cakes, candies, etc.)

△ Supporting machinery for soldering electronic components.

△ Industrial pharmaceuticals, rubber and plastic sheets, heat treatment of electrical components, and special condition conveyor belts that are heat-resistant and non-stick.

△ Transportation of automotive parts with rust-inhibiting adhesives, as well as conveyor belts for corrosive materials such as acids and bases.

Specifications of the seamless belt

1. Seamless belts are classified into models such as 200, 300, 400, 500, 600, 900, 1200, etc., based on the type of fusing belt.

2. Major brands of fusing machines compatible with these belts include Peak, Heavy Machine, Jiayou, Jiatians, Weishi, Yuzhou, Prince, Hongguang, Abalone, etc. The specifications of the fusing machine belts may vary by model.

Colors of the seamless belt:

The standard colors are black, white, and brown.

Thickness of the seamless belt:

The general thickness of the seamless belt is 0.35~0.75mm. Length 12m can also be customized according to customer needs.

Anti-deviation of the seamless belt:

To prevent deviation, the seamless belt can have guiding strips added to avoid misalignment.
