Diaphragm Pump: QBY Type Stainless Steel Air-Operated Diaphragm Pump Corrosion Resistant Diaphragm Pump

Construction Materials-Other Building Materials
Expand

Product Content

Category
Construction Materials-Other Building Materials
The QBY series stainless steel pneumatic diaphragm pump produced by our company is a new type of conveying machinery that uses compressed air as the power source. It can pump various corrosive liquids, liquids with particles, high-viscosity, easily volatile, flammable, and highly toxic liquids. Its performance parameters are similar to those of WLLDENPVMPS from Germany and MARI0WPUMPS from the USA.
stainless steel pneumatic diaphragm pump Applications:


 ⑴ The pump can suction peanut butter, pickles, mashed potatoes, small sausages, jam, apple paste, chocolate, etc.
 ⑵ The pump can suction paints, resins, and pigments.
 ⑶ Adhesives and glues of all types can be pumped.
 ⑷ Various glazes for tiles, ceramics, bricks, and pottery.
 ⑸ After drilling an oil well, the pump can suction sediments and grouting.
 ⑹ The pump can suction various emulsions and fillers.
 ⑺ The pump can suction various wastewater.
 ⑻ The pump can be used to suction bilge water from tankers and barges.
 ⑼ The pump can suction hops and fermentation powder, syrup, and sugar concentrate.
 ⑽ The pump can suction accumulated water in mines, tunnels, and slag from ore dressing. It can also suction cement grouting and mortar.
 ⑾ Various rubber slurries.
 ⑿ Various abrasives, corrosives, oil, mud, and cleaning of oil sludge and general containers.
 ⒀ Various highly toxic, flammable, and volatile liquids.
 ⒁ Various strong acids, strong bases, and highly corrosive liquids.
 ⒂ Various high-temperature liquids, can withstand up to 150℃.
 ⒃ As a pre-pressurizing device for various solid-liquid separation equipment.



diaphragm pumpPerformance Parameters:
Model Flow
(m 3 /h)
Head
(m)
Outlet Pressure
(kgf/cm 2)
Suction Lift
(m)
Max Allowable Particle Diameter
(mm)
Max Supply Air Pressure
(kbf/cm 2)
Max Air Consumption
(m 3 /min)
Material
Aluminum Alloy Stainless Steel Cast Iron Reinforced Polypropylene
QBY-10 0~0.8 0~50 5 5 1 7 0.3
QBY-15 0~1 0~50 5 5 1 7 0.3
QBY-25 0~2.4 0~50 5 7 2.5 7 0.6
QBY-40 0~8 0~50 5 7 4.5 7 0.6
QBY-50 0~12 0~50 5 7 8 7 0.9 /
QBY-65 0~16 0~50 5 7 8 7 0.9 /
QBY-80 0~24 0~50 5 7 10 7 1.5 /
QBY-100 0~30 0~50 5 7 10 7 1.5 /
