Product Name: YJV Low Voltage Cable
Model: ZRYJV
Specification: 4*185
Voltage: 0.6/1KV
Business hotline: Transport mode: logistics or special vehicle transportation
1. Product Features and Uses
Cross-linked polyethylene insulated power cables have the characteristics of high mechanical strength, good environmental stress resistance, excellent electrical performance, corrosion resistance, light weight, simple structure, and convenient use. This product is suitable for transmission and distribution lines with rated AC voltage Uo/U of 0.6/1kV and below.
The main feature of flame-retardant power cables is that the cable is not easy to ignite or when ignited, the burning is limited to a certain range, suitable for places with high cable laying density such as power plants, subways, tunnels, high-rise buildings, large industrial and mining enterprises, oil fields, coal mines, etc.
The main feature of fire-resistant power cables is that the cable can maintain normal operation for a certain period of time when ignited, suitable for places related to fire safety and fire rescue such as nuclear power plants, subways, tunnels, and high-rise buildings.
The feature of low-smoke halogen-free flame-retardant cables is that the cable not only has flame-retardant properties, but also has low smoke generation and harmlessness (small toxicity and corrosion), suitable for places with special requirements for cable flame retardancy, smoke density, toxicity index, etc., such as subways, tunnels, nuclear power plants, etc.
2. Product Standards
This product is organized and produced according to GB/T 12706-2002 or IEC 60502 standards, and can also be produced according to other standards required by users.
In addition to the above standards, the flame-retardant cables are divided into three different flame-retardant categories A, B, C according to the GB/T18380.3-2001 standard. Category A has excellent flame-retardant performance, which users can choose according to their needs.
The fire resistance of fire-resistant cables should comply with GB/119216.21-2003.
Halogen-free low-smoke flame-retardant cables are organized and produced according to enterprise standards. The flame-retardant performance is divided into three different flame-retardant categories A, B, C according to the GB/T18380.3-2001 standard. The smoke concentration is tested according to the GB/T17651-1998 standard, and the pH value and conductivity should comply with the GB/T17650.2-1998 standard.
3. Product Models
Normal cable models
YJV, YJLV cross-linked polyethylene insulated PVC sheathed power cables
YJY, YJLY cross-linked polyethylene insulated PE sheathed power cables
YJV22, YJLV22 cross-linked polyethylene insulated steel tape armored PVC sheathed power cables
YJV23, YJLV23 cross-linked polyethylene insulated steel tape armored PE sheathed power cables
YJV32, YJLV32 cross-linked polyethylene insulated fine steel wire armored PVC sheathed power cables
YJV33, YJLV33 cross-linked polyethylene insulated fine steel wire armored PE sheathed power cables
