1 Screw diameter: 50mm
2 Screw L/D ratio: 30:1
3 Material: 38CrMoALA.
4 Processing technology: Forging, tempering, nitriding.
5 Barrel: Stainless steel heating and 3-stage cooling fans (2 units).
6 Barrel heating zones: Divided into 3 zones with each zone at 2400W.
7 Maximum extrusion rate: 30 to 50 kg per hour.
8 Reducer: National standard hard tooth surface reducer, model 146.
9 Main motor: Power (11KW), Shanghai Lipu.
10 Die head: 120mm to 60mm die change ports (2 units).
11 Die head material: 45# steel, forged, hard chrome plated, precision polished.
12 Die head structure: Single-layer co-extrusion.
13 Die head heating: Stainless steel heating ring, power (4800W).
14 Cooling film air ring single outlet 620 type: (2 units at the base).
15 Cooling film blower: (4KW)
