Liaoning Sand Pump Pipe
Two key indicators: tensile strength and impact resistance. The level of tensile strength reflects the pressure rating of the pipe material, which directly indicates the ability of the pipe to withstand long-term pressure conditions and sudden water impact (pressure fluctuations) without breaking. Through departmental sampling tests, we found that the tensile strength of ordinary polyethylene mining pipes on the market is generally below 15Mpa. Such low tensile strength poses significant safety concerns for long-term use in pressure pipelines. In contrast, the ultra-high molecular weight polyethylene mining pipes developed by our company have a tensile strength of over 20Mpa, a hard indicator that is currently unmatched by other mining pipes.
Slurry pipes, mortar pipes, mud discharge pipes, and wear-resistant mud delivery pipes are made from ultra-high molecular weight polyethylene material, producing specialized pipes for sand delivery, suitable for slurry transport.
Liaoning Sand Pump Pipe performance is as follows:
1. The ultra-high molecular weight polyethylene sand delivery pipe is lightweight, only one-eighth the weight of steel pipes; flanged connections facilitate installation and disassembly, shortening startup time and improving efficiency.
2. The ultra-high molecular weight polyethylene sand delivery pipe has good flexibility and elasticity, with the pipe wall able to bend without breaking; the pipes can be directly connected, bending in water and effectively resisting wind and waves; on land, connections can be made in areas with uneven surfaces within 30 degrees, allowing for direct installation without ground preparation.
3. The wear resistance of the ultra-high molecular weight polyethylene sand delivery pipe is 4-8 times that of steel pipes, resulting in a longer service life; the pipe material is UV resistant and aging resistant, with a lifespan of 8-15 years depending on the sand content.
4. The length of the ultra-high molecular weight polyethylene sand delivery pipe is 8-12 meters or customized according to customer requirements; each pipe is fitted with movable metal flanges at both ends, allowing for direct bolt connections between pipes; the inner lining of the pipe mouth is reinforced with a steel ring, ensuring that the pipe mouth remains undistorted, unbroken, and leak-proof during long-term installation and disassembly, ensuring high efficiency in delivery.
5. The inner and outer walls of the pipe are smooth, with a low friction coefficient, resulting in a transport efficiency that is 20-30% higher than that of steel pipes.
6. Whether used on land or in water, it is cost-effective, safer, and more convenient for long-term use.
Liaoning Sand Pump Pipe engineering cases:
1. Tianjin Junlian Shipbuilding Ocean Engineering Technology Co., Ltd. (1000 meters Φ159 ultra-high molecular sand pump pipe and Φ500*800mm floating body)
2. Sanjiangkou Sand Field, Tongjiang City, Heilongjiang Province (1000m Φ325 ultra-high molecular pipe sand pump and Φ700*1200mm pipeline floating body)
3. Guangzhou Hangtong Shipbuilding Co., Ltd. (1300 meters Φ250 mud discharge pipeline and Φ500*800mm floating body)
4. Shandong Provincial Water Conservancy Dredging Engineering Office φ560mmX1550mmX1400mm floating body 315 pairs
5. Jining Port and Navigation Engineering Office φ600mmX1400mmX1700mm floating body 280 pairs
6. Jiangsu Dongfang Ecological Dredging Engineering Co., Ltd. φ315mmX1100mmX1100mm floating body 150 pairs
7. Liaoning Jinbowan Port and Navigation Engineering Co., Ltd. φ480mmX1300X1300mm floating body 270 pairs
8. Guangdong Jindonghai Group Co., Ltd. φ750mmX1600mmX2000mm floating body 237 pairs
9. Yingkou Port - Dredging Engineering Co., Ltd. φ780mmX1600X1900mm floating body 315 pairs
Contact:Manager Zhao
Mobile:18623755437
Phone: 0379-60692512
Fax: 0379-65260950
Email: 874689613@qq.com
Website: www.lygrsjw.com
Factory Address: Henan Province, Luoyang City Mengjin County, Matun Town, Zhejiang Business Industrial Park
Luoyang Guorun Pipe Industry Co., Ltd., welcome new and old customers to call for consultation and negotiation.
