Henan Steel Belt Corrugated Pipe Manufacturer

Using U-shaped steel belt composite PE materials, the pipe significantly improves ring stiffness without increasing costs, with strength greatly enhanced compared to winding pipes and spiral pipes at the same weight. This can solve a series of problems such as heavy loads, and the advantages of large-diameter pipes are even more apparent. Currently, the production of pipe diameters ranges from DN300mm to DN2400mm, with ring stiffness maintained above 8KN/m2, which is lighter and stronger than concrete pipes and other plastic pipes.

The composite of each layer is performed in a molten plastic state; this is completely different from the secondary melting and forming of winding pipes (hollow wall pipes), ensuring that each layer is fully bonded together with very high adhesion strength.

The steel belt surface undergoes special pretreatment to enhance the corrosion resistance of the steel and the bonding strength between the steel and plastic, improving the peel strength. The pipes are formed by winding in a fully melted state of the plastic raw material, resulting in a solid and reliable overall structure. By using special materials and processes, both the corrosion problem of the steel plate and the adhesion to the PE material are resolved, ensuring that the pipeline has a service life similar to that of pure plastic pipes, guaranteed to exceed 50 years.

Connections can be made using electric heat fusion, heat shrink connections, internal and external extrusion welding, or a combination of various connection methods, ensuring a secure connection. Reliable connections can achieve zero leakage in the pipeline. PE Henan Steel Belt Corrugated Pipe Manufacturer

Henan Steel Belt Corrugated Pipe Manufacturer Pipe Characteristics:

1. Chemical Resistance: Not contaminated, resistant to corrosion from wastewater and chemicals, and not corroded by decaying substances in the soil;

2. Impact Resistance: The pipe wall uses a 'U'-shaped structure, resistant to impact and pressure, and will not rupture under foundation settlement; it also has strong recovery properties after deformation, adapting well to the foundation;

3. Aging Resistance: The pipe is typically black and can withstand direct sunlight during storage and construction;

4. Cold Resistance: The pipe will not crack or leak in environments as low as -60℃;

5. Lightweight: Easy to transport and convenient for construction, weighing only 1/8 of concrete pipes, requiring only an excavator for burial without the need for large equipment;

6. Convenient Connections: The pipes can be connected outside the trench first and then pushed into the trench with an excavator, reducing project time and costs;

7. Superior Wear Resistance: More wear-resistant than steel and concrete pipes, with strong capacity for transporting domestic wastewater and waste;

8. Excellent Drainage Flow: Smooth interior reduces friction, facilitating fast drainage;

9. Economic Efficiency: Low construction, management, and maintenance costs;

10. Environmental Impact: HDPE is a non-toxic material, harmless to land and the environment, and can be recycled.

11. Good Stability of Pipeline Systems: The round external rib structure of Henan Steel Belt Corrugated Pipe not only increases the ring stiffness of the pipe but also provides root resistance, addressing the tension and topwell issues caused by longitudinal displacement of the pipeline.

12. Fully Reliable Ring Stiffness: Due to the elastic modulus ratio of steel and plastic materials being greater than 200 and the weight ratio greater than 7.85, the steel belt reinforcement makes the pipes (especially large diameter pipes) have sufficient safety and reliable ring stiffness, as well as a relatively high stiffness-to-weight ratio compared to pure plastic pipes.

Henan Steel Belt Corrugated Pipe Manufacturer Application Fields:

Civil Engineering: Underground drainage and sewage pipes;

Road Engineering: Drainage and seepage pipes for railways and highways;

Industry: Widely used for industrial wastewater pipes;

Construction Engineering: Rainwater pipes, underground drainage pipes, sewage pipes, ventilation pipes, etc., for buildings;

Sewage collection pipes for landfills;

Large Ports and Docks: Drainage and sewage pipes for large airports, ports, and dock projects;

Sports Venues: Drainage pipes for sports venues such as golf courses and football fields;

Hydraulic Engineering: Used for water source pipes, irrigation pipes, and water conveyance and drainage in hydropower stations;

Mines: Ventilation, air supply, drainage, and slurry pipes for mines;

Communication Pipes: Communication protection pipes for railways and highways, communication cables, and optical cables;

Water Storage Systems: Water storage systems that intercept slow water flows;

Agricultural Engineering: Drainage and irrigation for farmland, orchards, tea gardens, and forest belts;

Seawater Transport Pipes.

Contact Person:Manager Zhao

Mobile:18623755437
Telephone: 0379-60692512
Fax: 0379-65260950

Company Website: www.lygrsjw.com
Email: 874689613@qq.com
Factory Address: Henan Province, Luoyang City, Mengjin County, Matun Town, Zhejiang Business Industrial Park
Welcome to purchase our polyethylene pipes, and we will provide you with excellent product services!
