Main Equipment Parameters:

WG-38 Type WG-51 Type WG-76 Type

Bending Diameter Range ≤Φ38 Steel Pipe (Wall Thickness ~2mm) ≤Φ51 Steel Pipe (Wall Thickness 2-3mm) ≤Φ76 Steel Pipe (Wall Thickness 2-3mm)

Bending Speed High Speed 10~12 R/min 4~6 R/min 3~5 R/min

Number of Bending Angles 9 9 9

Bending Angle 300 200 200

Minimum Bending Angle 30 30 30

Motor Power 2.2KW-6 Poles 3KW-4 Poles 4KW-4 Poles

Power Supply Three-phase AC 380V, 50Hz Three-phase AC 380V, 50Hz Three-phase AC 380V, 50Hz

Footswitch Voltage DC 5V DC 5V DC 5V

Main Machine Dimensions 920x650x850mm 930x680x850mm 940x750x850mm

Overall Weight 210kg 260kg 300kg

Instructions for Use of the Square Pipe Bender

1: Please read the product manual carefully before using the Square Pipe Bender, correctly connect the power line, and add gear oil or machine oil to the gearbox before first use. Change the oil after about three months of use, and then every two years thereafter.

2: Do not overload the equipment (e.g., using the 38 series machine for bending pipes with a diameter greater than 38mm).

3: Regularly check the square pipe bender to ensure the power connection is secure, the motor surface temperature is normal, and that there are no abnormal sounds during operation.
