Speashock threaded filter FIG13, cast iron material, threaded connection. Standard stainless steel filter mesh with 0.8mm aperture. Other apertures, numbers, and alloy filter meshes are also available. Threaded connections can be drilled on the filter valve cap for drainage or discharge valve as needed.
Speashock filter
Speashock threaded filter FIG13 is used to ensure that all devices are protected from blockages and damage caused by impurities, rust, and welding slag inside pipelines. This reduces maintenance costs and production losses.
The filter can be installed in steam pipelines, oil pipelines, water pipelines, and compressed air system pipelines to protect various measuring instruments, pumps, pressure reducing valves, temperature control valves, steam traps, and other equipment.
Filter
Speashock threaded filter FIG13 comes in a variety of options, including filters made of cast iron, ductile iron, cast steel, stainless steel, etc., with diameters ranging from 15mm to 250mm and various connection specifications to meet various industrial applications.
Fig12/13/14/16Y type filters, threaded connections, made of ductile iron, cast iron, cast steel, and stainless steel, can be used in steam, water, and other fluid systems.
Fig33/34/36/37Y type filters, flange connections, made of cast iron, cast steel, stainless steel, and ductile iron.
Fig7 basket type filter, flange connection, made of carbon steel. Holes can be drilled on the body to install pressure gauges and drain valves.
Filter mesh
Speashock threaded filter FIG13 has a complete range of filter mesh specifications, with apertures ranging from 1/64' to 3/16'' or 40 mesh to 200 mesh. Depending on the material, the filter mesh materials include brass, stainless steel, Monel high-strength corrosion-resistant nickel-copper alloy, etc. Note: Do not install finer mesh than required; 200 mesh filter mesh is recommended only for gas or air pipelines.
Installation
Speashock threaded filter FIG13 is horizontally installed in steam main pipes with a diameter greater than 1' (DN25) to prevent condensation accumulation in the filter, which can cause water hammer and restrict the filtration area.
Speashock FIG12 Filter Introduction
Speashock FIG12 Y-type filter, ductile iron material, threaded connection. Standard stainless steel filter mesh with 0.8mm aperture. Other apertures, numbers, and alloy filter meshes are also available. Drainage or discharge valves can be drilled on the filter valve cap according to requirements.
Speashock filter
Speashock filters are used to ensure that all devices are protected from blockages and damage caused by impurities, rust, and welding slag inside pipelines, reducing maintenance costs and production losses.
Speashock FIG12 filters can be installed in steam pipelines, oil pipelines, water pipelines, and compressed air system pipelines to protect various measuring instruments, pumps, pressure reducing valves, temperature control valves, steam traps, and other equipment.
Filter
Speashock FIG12 Filter has a complete range of options, including filters made of cast iron, ductile iron, cast steel, stainless steel, etc., with diameters ranging from 15mm to 250mm and various connection standards to meet various industrial applications.
Fig12/13/14/16Y type filters, threaded connections, made of ductile iron, cast iron, cast steel, and stainless steel, can be used in steam, water, and other fluid systems.
Fig33/34/36/37Y type filters, flange connections, made of cast iron, cast steel, stainless steel, and ductile iron.
Fig7 basket type filter, flange connection, made of carbon steel. Holes can be drilled on the body to install pressure gauges and drain valves.
Filter mesh
Speashock FIG12 Filter has a complete range of filter mesh specifications, with apertures ranging from 1/64' to 3/16'' or 40 mesh to 200 mesh. Depending on the material, the filter mesh materials include brass, stainless steel, Monel high-strength corrosion-resistant nickel-copper alloy, etc. Note: Do not install finer mesh than required; 200 mesh filter mesh is recommended only for gas or air pipelines.
Installation
To prevent condensation accumulation in the filter, which can cause water hammer and restrict the filtration area, filters with a diameter greater than 1' (DN25) in steam main pipes should be horizontally installed.
Speashock FIG13 Filter Ordering Information
