Specialized Production of 12K Silicone Carbon Fiber Heating Wire

Product Name/PART NAME

Carbon firber Heating wire
PRODUCT      MODEL：No.10480
ISULATION   VOLTAGE：1500V
ISULATION  RESISTOR：≧100MQ
RATED TEMPERATURE：80℃
RATED       VOLTAGE：600V
RESISTOR     RANGE：133、66、33、17、11Ω/M
DIAMETER     RANGE：Ø1.8~6.0mm
【ENGLISH EDITOR】
PRODUCT      MODEL：No.10480
ISULATION   VOLTAGE：1500V
ISULATION  RESISTOR：≧100MQ
RATED TEMPERATURE：80℃
RATED       VOLTAGE：600V
RESISTOR     RANGE：133、66、33、17、11Ω/M
DIAMETER     RANGE：Ø1.8~6.0mm
【中文编辑】
Product Application/APPLY
 ---Infrared health blanket. Electrical blanket Heating PAD Heating Clothing.Electrical glove,And so on.
【ENGLISH EDITOR】
 ---Infrared health blanket. Electrical blanket Heating PAD Heating Clothing.Electrical glove,And so on.
【中文编辑】
Product Structure&Material Explanation/Structure&Material:
The thermal inertia of the heating wire is small, heating fast, the electric heating conversion rate reaches over 99%, energy-saving; It takes 1~3 minutes to reach the required temperature for electric heating blankets and electric heating bed mats after being electrified
High far infrared radiation: The wavelength of 8~15uM far infrared is beneficial to the human body
The heating element has good oxidation resistance, not easy to age, durable
The resistance value is stable, heating is uniform, heating temperature and energy can be controlled by the length and working voltage of the heating wire
Bending test of the product: over 5000 times, no abnormalities (tested according to UL, IEC standards)
Bending test of the product: over 25000 times, no abnormalities (tested according to UL, IEC standards)
常Common Carbon Fiber Specifications: 1K, 3K, 5K, 6K, 9K, 12K, 15K, 18K, 24K, 30K, 36K, 48K
【ENGLISH EDITOR】
Heating Quickly,High Efficiency of  Electricity translates into heat about 99%,It can make the Blanket reach the temperature of people's body in
   very short time about 1~3 minutes
High infrared radiation: wavelength about 8~15um is good for the body.
Heating stability is good, long life
Resistor value is stable, heat is even, the heating temperature and energy can be controlled by the length and working voltage of the heating wire
Bend test NO: 5000 (According to UL/IEC Standard)
Circumnutating Test NO: 25000 (According to UL/IEC Standard)
General specification: 1K, 3K, 5K, 6K, 9K, 12K, 15K, 18K, 24K, 30K, 36K, 48K
【中文编辑】
Packing List
Minimum Order Quantity: 2000M (Buyer bears the freight for less than 5000M)
Packing: 500M/roll
Note: Can be processed according to requirements, cut and processed, joint processing, joint waterproof processing, etc.

【中文编辑】
Service Commitment:
From the date when the customer purchases Xingguan products, the Xingguan customer department will establish customer files. If any problems occur within the warranty period due to the company's own processing defects causing quality problems, customers can obtain replacement or return treatment with the receipt.
