South Wind Brand MPP Modified Polypropylene Cable Protection Pipe

Material: MPP Place of Origin: Dongguan Nanfeng Plastic Pipe Co., Ltd. Brand: Nanfeng Application Location: Power Cable System [Brand Manufacturer Direct Sales] Nanfeng MPP Modified Polypropylene Cable Protection Pipe, Detailed Description of Municipal Cable Protection Pipe: Manufacturer (Place of Origin): Dongguan Nanfeng Plastic Pipe Co., Ltd. Location/Manufacturer: Cao Le Xia Jiao Village, Xiegang Town, Dongguan City Color: Red Nominal Outer Diameter: 110~250 (mm) Nominal Pressure: 1.0~1.6 (Mpa) Material: MPP Appearance: Red Use: Wire Sheath Wall Thickness: 6.0 (mm) Length: 6-9 (m) Recommended: PE Water Supply Pipe HDPE Double-Wall Corrugated Pipe Cable Sheath Pipe PE Gas Pipe PE Net Cage Internal Threaded Coupling Product Introduction: Nanfeng MPP Modified Polypropylene Cable Protection Pipe, with complete specifications (110mm~250mm), easy to install, green and environmentally friendly, widely used in various municipal engineering projects. Consultation hotline: 13829204225 Mr. Fu. Product Specifications: 110mm~250mm Product Knowledge: MPP Power Cable Protection Pipe 1. Product Name: MPP Power Pipe, also known as MPP Cable Pipe, MPP Power Cable Protection Pipe. 2. Product Type: MPP Power Pipe is divided into ordinary and reinforced types, with reinforced types further divided into excavation pipes and non-excavation pipes, the so-called MPP non-excavation pipes are also known as MPP Jacking Pipes, MPP Torpedo Pipes, MPP Pulling Pipes. 3. Raw Materials: Mainly made from PP powder (modified polypropylene). 4. Connection Method: Use a welding machine for hot melt welding. The melting point is around 200 degrees and must not exceed 220 degrees. Once the temperature is reached, the two ends can be connected. (Due to the connection method of MPP pipes being hot melt welding, if the welding joint is poor, it may damage the cable or possibly flatten it, so MPP power pipes must be made from all new materials.) 5. Product Color: MPP Power Pipe is orange-red. 6. Product Length: Generally, it is 6 meters per piece, but if the order quantity is large, in order to reduce costs (freight and welding fees), it can be made into 6-13 meters per piece. 7. Summary of Product Advantages: Modified polypropylene (MPP) power pipes have high-temperature resistance and external pressure resistance, suitable for high-voltage transmission line cable pipes above 10KV. This product has passed the inspection of the National Chemical Building Materials Testing Center and has achieved good social and economic benefits. 8. Detailed Introduction of Product Features: 1. MPP power pipes have excellent electrical insulation properties. 2. MPP power pipes have high heat deformation temperature and low-temperature impact performance. 3. MPP power pipes have higher tensile and compressive strength than HDPE. 4. MPP power pipes are lightweight, smooth, have low friction, and can be hot melt welded. 5. MPP power pipes can be used at temperatures ranging from -5 to 70°C. 6. Construction Notes: - During transportation and construction of the pipes, do not throw, impact, scratch, or expose to sunlight. - When hot melt welding, the axes of the two pipes must be aligned, and the end faces should be cut vertically and smoothly. - Adjust processing temperature, time, and pressure according to weather conditions. - The minimum bending radius of the pipe should be ≥75 times the outer diameter of the pipe. 9. Product Application Range: Widely used in municipal, telecommunications, power, gas, water supply, and thermal pipeline projects. Urban and rural non-excavation horizontal directional drilling power pipe projects, as well as lighting excavation power pipe projects. Urban and rural non-excavation horizontal directional drilling sewage discharge pipe projects, industrial wastewater discharge projects. 10. Product Physical Properties: Main physical and mechanical properties of MPP pipes: | No. | Item | Requirement | Test Method | |----|------|-------------|-------------| | 1 | Density | 0.91-0.96 g/cm³ | GB1033-86 | | 2 | Sliding Friction Coefficient | <0.35 | GB/T3960-89 | | 3 | Tensile Strength (23±2°C) | ≥24.0 Mpa | GB/T1040-92 | | | Tensile Strength (70±2°C) | ≥18.0 Mpa | | | 4 | Welded Tensile Strength (23±2°C) | ≥21.6 Mpa | GB/T1040-92 | | 5 | Bending Strength (23±2°C) | ≥37.0 Mpa | GB/T9341-2000 | | 6 | Bending Elastic Modulus | 1000-1200 Mpa | GB/T9341-2000 | | 7 | Flattening Test (1/2 pipe diameter, -5°C) | No rupture | GB9647-88 | | 8 | Vicat Softening Point (10N, 50°C/h) | ≥120°C | GB/T1633-2000 | | 9 | Out-of-roundness | 3.6-5.0 mm | GB/T13633-2000 | | 10 | Minimum Allowable Bending Radius | ≤75D m | | | 11 | Material Qualitative | Modified Polypropylene MPP | ASTME168-99 | | 12 | Drop Hammer Impact Test (-5°C/8h, R20) | D > 160, 10kg*2m
D ≤ 160, 6kg*2m
D ≤ 125, 5kg*2m | GB/T6112-1985 | 11. Common Product Specifications are as follows: Unit: Also produced by Hangzhou Tongdu Industrial Co., Ltd. | Nominal | Outer Diameter | Ring Stiffness | 20KN/㎡ | Ring Stiffness | 20KN/㎡ | Ring Stiffness | 20KN/㎡ | |--------|----------------|----------------|----------|----------------|----------|----------------|----------| | Nominal Wall Thickness | Weight (Kg/m) | Nominal Wall Thickness | Weight (Kg/m) | Nominal Wall Thickness | Weight (Kg/m) | | | 110 | 5.7 | 1.812 | 7.2 | 2.252 | 9.1 | 2.782 | | 125 | 6.4 | 2.345 | 8.2 | 2.908 | 10.3 | 3.570 | | 140 | 7.2 | 2.912 | 9.2 | 3.648 | 11.6 | 4.491 | | 160 | 8.2 | 3.784 | 10.5 | 4.745 | 13.2 | 5.844 | | 180 | 9.2 | 4.769 | 11.8 | 5.986 | 14.9 | 7.396 | | 200 | 10.3 | 5.918 | 13.1 | 7.396 | 16.5 | 9.107 | | 225 | 11.6 | 7.480 | 14.8 | 9.367 | 18.6 | 11.54 | | 250 | 12.8 | 9.160 | 16.4 | 11.54 | 20.6 | 14.19 | | Nominal Outer Diameter | Nominal Ring Strength | |------------------------|----------------------| | 110 | 3060 | | 125 | 3800 | | 140 | 4800 | | 160 | 6300 | | 180 | 7900 | | 200 | 9800 | | 225 | 12400 | | 250 | 15300 | | 40KN/㎡ | 80KN/㎡ | |----------|----------| | 3700 | 4600 | | 4800 | 5900 | | 6000 | 7500 | | 7900 | 9700 | | 10000 | 12400 | | 12300 | 15200 | | 15600 | 19300 | | 19300 | 23800 | About Us: Dongguan Nanfeng Plastic Pipe Co., Ltd. is a brother company of Hong Kong Nanfeng International (Group). It is a qualified unit of the China Light Industry Machinery Association "Key Technologies of Plastic Pipes" training. It is also a standard unit for "Plastic Pipe Profile Performance Testing" in the National Plastic Processing Industry Information Center and a "Vice President Unit" of the Guangdong Building Materials Council. The leading products include PE100 and PE80 water supply pipes/fittings ranging from 20mm to 1400mm; 110mm to 1400mm HDPE sewage (drainage) pulling pipes (non-excavation jacking pipes); PE100 and PE80 gas pipes/fittings ranging from 25mm to 630mm; 225mm to 800mm HDPE double-wall corrugated pipes; PE same-layer drainage pipes/systems; PE siphon pipes/siphon drainage systems; HDPE hollow wall winding pipes ranging from 200mm to 3000mm; HDPE winding reinforced pipes ranging from 200mm to 3300mm; 110mm to 250mm MPP modified polypropylene cable protection pipes; PE net cage pipes/net cage breeding systems; communication sheath pipes ranging from 32mm to 250mm; PP-R cold and hot water pipes; PP-R steady-state pipes; silicon core pipes; PE fittings, etc. The products are complete in specifications, easy to install, and environmentally friendly, widely used in municipal engineering construction, industrial and civil building water supply and drainage, telecommunications, petrochemicals, agricultural irrigation, and many other fields. The company has strong product research and development capabilities, mold manufacturing capabilities, and has strong technical support with advanced production equipment and processes, capable of organizing the production of various large-diameter PE pipes and matching fittings for different purposes in South China, with an annual production capacity exceeding 50,000 tons. In order to enhance independent research and development capabilities while developing simultaneously, the company has invested heavily in constructing a research and development center with international standards, researching and developing new technologies in the plastic industry, and providing comprehensive technical support and services to customers in a timely manner. The company adheres to the business philosophy of "Quality is life, technology is the leading, and customer satisfaction is the purpose," striving to promote the development of the plastic and related industries to improve the living environment for people in China and beyond. Contact Information: Dongguan Nanfeng Plastic Pipe Co., Ltd. Contact Person: Mr. Fu (Marketing Department) Mobile Phone: 13829204225 Phone: 086 0769 87130520 Fax: 086076987130526 Address: Cao Le Xia Jiao Village, Xiegang Town, Dongguan City, Guangdong Province, China
