Q961N Q921N Q941N Q911N Electric High Pressure Ball Valves

Construction Materials-Other Building Materials
Expand

Product Content

Category
Construction Materials-Other Building Materials
**Q961N Q921N Q941N Q911N Electric High-Pressure Ball Valve Overview:** The electric high-pressure ball valve consists of a compact electric actuator and a forged high-pressure ball valve body. The ball core of the valve body is made of stainless steel, and the body is forged under high pressure to ensure that the ball valve can effectively withstand pressure imbalances in the pipeline during use, allowing for safe operation. The ball core is finely polished for good smoothness. The interior uses nylon sealing, which has high temperature resistance and enhanced sealing properties. During operation, the ball core tightly adheres to the nylon seal with no gap rotation, and the elasticity of the nylon seal aids in self-tightening, providing excellent sealing performance. The valve's opening and adjustment are accomplished by using industrial signals (4~20mA) with a 220V power supply to drive the valve stem, which rotates the ball core. **Q961N Q921N Q941N Q911N Electric High-Pressure Ball Valve Parameters:** - General Model: Q961N Q921N Q941N Q911N - Nominal Diameter: DN10mm~DN80mm - Pressure Range: 10MPa~32MPa - Operating Temperature: -29℃~200℃ - Applicable Media: Gas stations, hydraulic stations - Valve Material: Stainless Steel 304 - Drive Mode: Electric, On-Off Type, Regulating Type **Q961N Q921N Q941N Q911N Electric High-Pressure Ball Valve Applications:** The electric high-pressure ball valve is particularly suitable for: hydraulic stations, gas stations, heat transfer oil, liquefied gas, oil pipelines, and various high-pressure pipeline applications for medium connection and switching regulation. The electric high-pressure ball valve is favored for its pressure resistance, temperature resistance, and wear resistance, making it one of the most popular ball valves in modern industrial transport pipelines. Shanghai Guanuo Valve Co., Ltd. mainly produces: pneumatic high-platform ball valves, electric high-platform ball valves, electric explosion-proof ball valves, pneumatic ball valves, electric explosion-proof butterfly valves, pneumatic butterfly valves, electric explosion-proof gate valves, pneumatic gate valves, electric explosion-proof stop valves, pneumatic stop valves, electric regulating valves, and pneumatic regulating valves.
Product Consultation
Supplier
Shanghai Guannuo Valve Manufacturing Co., Ltd.
location
China Shanghai
About Us
Sure, here is the translation of the provided text from Chinese to English: --- Shanghai Guano Valve Manufacturing Co., Ltd. was founded in 2007 and is currently located in Xinghu Industrial Park, Fengxian District, Shanghai. Our main products include: electric valves, pneumatic valves, electric ball valves, pneumatic ball valves, electric gate valves, pneumatic gate valves, electric butterfly valves, pneumatic butterfly valves, electric stop valves, pneumatic stop valves, electric regulating valves, pneumatic regulating valves, self-acting regulating valves, high-pressure valves, low-temperature valves, hydraulic control valves, ceramic valves, corrosion-resistant valves, mining valves. General-purpose valves include: gate valves, butterfly valves, ball valves, stop valves, check valves, safety valves, plug valves, filters, trap valves, water control valves, blind flange valves, black water valves, HVAC valves. We have a strong R&D team and advanced casting techniques combined with modern technology. Our comprehensive after-sales service has made significant contributions to various industries. Our design standards include: GB Industrial General Valves, JB Ministry of Machinery, HG Ministry of Chemical Industry, API American Petroleum Institute, AWWA American Water Works Association standards, ANSI American National Standards, JIS Japanese Standards, DIN German Standards, BS British Standards, FOCT Former Soviet Union National Standards, MIL Government Standard, ISO International Standards, etc. The fields our valves are involved in include: aviation, scientific research, shipbuilding, deep-sea mining, oil industry, special mining and industrial sectors, thermal power generation, water conservancy projects, hydropower, nuclear power plants, chemical industry, food industry, urban construction, etc. Our certifications include: ISO9001, ISO14000, ISO18000 quality system certification, API-6D American Petroleum Institute certification, EU CE safety certification, national power grid first-class supplier membership, China National Oil Corporation (CNOC) access member unit, recommended construction unit. Shanghai Guano Valve Manufacturing Co., Ltd. operates under the principles of "quality for survival, reputation for development, innovation and progress." With our expertise, quality, and integrity, we provide a series of comprehensive solutions for customers in various fields and aim to become a valve manufacturer on par with global brands! Guano Valves welcomes new and old customers to visit and guide us at our factory, working together to create a bright future. ---
