Price of Trifluoro Rod
Construction Materials-Other Building Materials
Expand
Product Content
Category
Construction Materials-Other Building Materials
PCTFE, or poly(chlorotrifluoroethylene), is a polymer compound formed by the polymerization of chlorotrifluoroethylene. Low molecular weight PCTFE is a liquid or waxy substance, while high molecular weight PCTFE appears as a white solid or dispersion. The solid density ranges from 2.1 to 2.2. The melting point is between 208 and 210°C. It exhibits resistance to heat, acids, alkalis, and organic solvents (except halides), but is not resistant to molten caustic alkalis and elemental fluorine. It is soluble in aromatic hydrocarbons. Its chemical resistance properties are second only to those of polytetrafluoroethylene (PTFE). PCTFE can be used as an engineering plastic. The tensile strength ranges from 3.096 to 4.135 MPa (316 to 422 kgf/cm²). It is commonly used in chemical equipment requiring high performance, insulation cables, radio components, capacitors, and heat or low-temperature resistant fittings, among others. The dispersion is used for anti-corrosion coatings and films. The synthesis methods for PCTFE include bulk polymerization, solution polymerization, and dispersion polymerization, using peroxides as initiators for free radical polymerization. PCTFE possesses excellent chemical stability, insulation properties, and weather resistance, suitable for long-term use at temperatures ranging from -196 to 125°C. Its mechanical strength and hardness exceed those of PTFE, and when made into films, it has good transparency and low gas permeability rates. PCTFE is suitable for applications involving contact with highly corrosive media, sealing and gasket materials in high-pressure systems, transparent materials for observation windows, and electrical insulation materials. Therefore, it has special significance in the chemical and atomic energy industries, although its price is higher than that of PTFE. Low molecular weight PCTFE has high density, excellent viscosity-temperature characteristics, and chemical corrosion resistance, making it suitable as a sealing liquid, lubricant, and balance fluid for navigation gyroscopes in high-corrosion environments. Applications: 1. Sealing and gasket materials for contact with highly corrosive media and high-pressure systems, and transparent materials for observation windows. 2. Electrical insulation materials. 3. Low molecular weight PCTFE as sealing liquids, lubricants, and balance fluids for navigation gyroscopes in highly corrosive media. Our company offers PCTFE rods, pipes, sheets, seals, gaskets, valve seats, and other products in various specifications. For specific specifications, refer to PTFE product specifications (PCTFE products comply with relevant enterprise standards). PCTFE Product Specifications: Project: Density (g/cm³): 2.10-2.18 Tensile Strength (MPa): ≥ 30 Elongation at Break (%): ≥ 20 Continuous Use High Temperature (°C): -200 to 150 Dielectric Strength (kV/mm): ≥ 15
Product Consultation
Supplier
Shanghai Qintu Sealing Parts Co., Ltd.
location
Shanghai
Main products
PTFE fiberglass, dispensing machine seal, PEEK washer, PTFE packing, PCTFE tube, Teflon coated silicone O-ring, PTFE back-up ring/gasket, PTFE with guide ring, ultra-high molecular weight polyethylene UPE, PTFE graphite, ultra-high molecular weight polyethylene, PTFE countersunk screw, PCTFE valve seat, dispensing machine seal, PEEK valve seat, PTFE with guide ring, moldless machined polyurethane PU, PTFE valve seat, face V-seal, PTFE polyimide, LNG fueling nozzle external seal, low-temperature V-seal, expanded PTFE sealing tape, bore V-seal, PTFE bushing, PEEK tube, polyoxymethylene (POM), PTFE+fiberglass, expanded PTFE round rod, reinforced PTFE products, PTFE fasteners, polyurethane, nylon, PCTFE rod, nylon PA, PTFE back-up ring, Teflon coated O-ring, polyoxymethylene POM, polyurethane PU, PEEK tube and rod seals, PTFE irregular parts, step seal, PTFE+graphite, expanded PTFE sealing tape, polyoxymethylene (POM), PTFE hex socket screw, G-rings, PEEK rod, polyurethane (PU), guide ring, flexible PTFE sealing tape and strip, shaft V-seal, high-pressure valve V-seal, PTFE irregular screw, polyoxymethylene, LNG seals and accessories, PTFE piston ring, PCTFE sheet, PTFE+polyimide, expanded PTFE round rod, Teflon coated fluororubber O-ring, PTFE diaphragm, G-rings and step seal, low-temperature resistant PCTFE products, LNG fueling nozzle, laser cutting head V-seal, PCTFE gasket, PTFE container, PTFE+carbon fiber, PTFE elastic tape, PTFE carbon fiber, PTFE pickling tank, LNG seal, rotary V-seal, polyurethane (PU)
About Us
Sure, here is the translation of the provided information: ``` Shanghai Qintu Sealing Parts Co., Ltd. is located in Fengxian District, Shanghai. Fengxian District is situated at the southeastern end of the Yangtze River Delta, in the southern part of Shanghai, facing Hangzhou Bay to the south and the Huangpu River to the north. It overlooks Minhang District across the river and is adjacent to Pudong New Area to the east, as well as Jinshan District and Songjiang District to the west. The company produces sealing parts mainly including PTFE series sealing parts, PCTFE series sealing parts, graphite sealing parts, PEEK, POM, nylon, PVDF, and other high-temperature and high-pressure sealing products and fluoroplastic products. We also offer customized sealing solutions for specific user requirements. The company has long-term and extensive cooperation with domestic peers in the sealing industry. We can design and produce special seals suitable for various harsh environments such as high and low temperatures, corrosive conditions. Our products strictly adhere to quality standards, and our processes are meticulously refined. High-temperature and corrosion-resistant products are exported worldwide and have received consistent praise from customers both domestically and internationally. Our company boasts a streamlined organizational structure, an excellent workforce, and rapid market responsiveness. We have always been committed to providing comprehensive service to our users, maintaining close cooperation and communication with them. We strive to offer reasonable prices and optimal quality to ensure that users receive the best products and services. In addition to supplying the entire range of PTFE products, we welcome feedback from users to further meet their expectations for both services and products. Our company adheres to the principles of "Honoring contracts and keeping promises" and "Quality first, customers foremost." We aim to improve our quality assurance system by adhering to the ISO9000 enterprise quality management system certification. With an unprecedentedly positive attitude and a spirit of continuous advancement, we look forward to working together with you to achieve brilliance in the 21st century. We warmly welcome new and old customers alike! ```
