Product Parameters (Ⅰ) Automatic Bag Feeder Bag Feeding Capacity: 1200 bags/h Adopts a three-position automatic switching working mode, pneumatically driven. Can store 200-300 empty bags. An alarm will alert when the bags are about to run out, and the packaging machine will automatically stop when all bags are used up. The packaging bags are woven bags with a plastic film lining, and the final dimensions need to be provided by the customer. (Ⅱ) Automatic Bagging Machine Bagging Capacity: 800-1200 bags/h Main Features: ① Vacuum bag suction, robotic arm for bagging ② Bag library shortage alarm ③ Insufficient compressed air pressure alarm ④ Bag detection and inflation function ⑤ Main components are made of stainless steel (Ⅲ) Air Bag Picker The vacuum suction cup picks up individual empty bags from the bag feeder. The pneumatic hand grips the empty bag, moves it to the center of the bagging machine, releases the grip, and then returns to continue picking bags. (Ⅳ) Bag Aligning and Feeding Device The shaping device centers the incoming empty bags, which are then fed to the designated position by the bag feeding device, waiting to be filled. (Ⅴ) Bagging Robotic Arm Grips both sides of the empty bag and sends it to the automatic bag gripping device. (Ⅵ) Automatic Bag Gripper The pneumatic gripper holds the empty bag delivered by the robotic arm and checks if it is secured properly (if not secured, the empty bag will be automatically blown away). The opening suction cup opens the bag mouth while checking if the bag mouth is open (if abnormal, the empty bag will be blown away). Once normal, the discharge port opens and extends into the bag mouth, notifying the electronic scale to discharge, with the material entering the packaging bag through the intermediate hopper. (Ⅶ) Horizontal Moving Cart (Bag Pusher) After the material enters the packaging bag, it ensures the material is fully settled, and then the horizontal moving cart sends it along a straight guide rail to the bag mouth shaping machine. (Ⅷ) Vacuum System with Blade Vacuum Pump The vacuum pump achieves a vacuum degree of 20 mbar, noise level ≤ 65 dB. Drive Mode: AC motor, 380V ± 10%, 50HZ. Motor Power: 1.5KW * 2 (Ⅸ) Bag Mouth Shaping Machine Works with the bag feeding cart to send the bag into the sealing unit, ensuring the bag mouth does not deform. The height is mechanically adjustable, and the feeding speed is continuously adjustable via frequency conversion. Drive Mode: AC motor, 380V ± 10%, 50HZ. Motor Power: 0.37KW (Ⅺ) Automatic Packaging Control System Utilizes imported programmable controllers, imported motor frequency speed control, and imported photoelectric and position detection components to form the main control system, achieving coordinated control of the entire packaging machine. The system features positive and negative pressure detection and includes both automatic/manual switching modes. The entire operating system is simple to use, fully functional, and easy to maintain. …………………………………………………………………………………………………………………………………………………………… Address: No. 70 Nankai Road, Shuo Fang Airport Industrial Park, Wuxi City (Hudong Industrial Park) - 8 Phone: 0510-82131722 88550806 Fax: 0510-82137653 Contact: Mr. Zhou Mobile: (0)13771089168 QQ: 2432242318 After-sales Service: 0510-88550806-648 or 698 E-mail: zhou@zybzjs.com Postal Code: 214028 Website: www.zybzjs.com
