| Product Material: | Nylon PA66 |
| Thread Specification: | Metric Thread (M), German Thread (PG), American Thread (NPT), British Thread (G) |
| Commonly Known As: | Nylon Cable Fixing Head, Nylon Waterproof Connector, External Compression Cable Clamping Connector, Plastic Waterproof Connector, Cable Waterproof Line Clamp, PG Type Nylon Cable Fixing Connector, M Type Waterproof Connector, MG Type Nylon Waterproof Cable Connector |
|
Thread Specification: |
Metric Thread M, complies with EU standards. |
|
Product Description: |
The precision and aesthetically pleasing design, combined with a locking nut structure that maintains high torque, provides exceptional tensile strength and airtightness, and can withstand submersion at 50 meters. This product has passed 1000 hours of UV resistance tests, with waterproof and tensile strength functions remaining unchanged. The product features corrosion resistance to acids, bases, chemicals, and general solvents, making it widely applicable in various fields such as machinery, automation, electrical, networking, connectors, telecommunications, and lighting. |
|
Protection Level : |
Within the specified socket range, and using an O-ring seal to tighten the locking head, achieving IP68-5Bar Color: Black (B), Gray (G), other colors can be customized; please consult our sales staff. |
|
Fire Rating: |
UL94V-2, up to V0 fire rating. |
|
Material: |
Parts A.C.E.F are made of UL recognized Nylon PA66 (Fire Rating UL 94V-2), parts B and D are made of EPDM weather-resistant rubber. Various sizes and rubber materials can be customized. |
| Working Temperature: | -40℃~＋100℃, can reach +120℃ for a short time. (Product specification sheets, ROHS statements, etc. can be requested after purchasing the product) |
