LCS-20 Open Bag (White Carbon Black) Automatic Quantitative Packaging Machine, a new product developed by our company, has been successfully used in Shandong Haihua White Carbon Black Factory and has been recognized by the manufacturer. This packaging machine has successfully filled the gap in the domestic white carbon black industry packaging. Due to the presence of gas in the material, there are problems such as incomplete packaging and inability to compress due to the large volume during the packaging process. This packaging machine thoroughly solves the above problems and replaces manual packaging. It has high weighing accuracy and uses lifting control feeding method. It reduces on-site dust, and the on-site control panel has a large screen touch screen, which is easy to operate, easy to understand, and has perfect functions. It can be widely used for packaging of ultra-fine powder materials, especially for the white carbon black packaging industry. Basic configuration: 1. Feeding bin 2. Lifting platform (bag clamping mechanism) 3. Feeding mechanism (with arc door) 4. Weighing mechanism 5. Computer weighing controller (touch screen) 6. Discharging mechanism (with lifting) Note: Those that are not within the weighing range and packaging capacity are non-standard scales, which need to be designed according to the actual requirements of the user. Main functions: ◆Automatically complete the material packaging control function, integrating weight display, packaging timing, process interlocking, and fault alarm; ◆It has automatic storage, recovery (copy) of debugging parameters function; ◆Automatically store the control parameters of ten packaging weights and the cumulative output, cumulative number of packages, total output, and total number of packages for each packaging weight; ◆Adopt single spiral frequency conversion fast, three-speed feeding method to improve measurement accuracy and speed; ◆High-brightness fluorescent double-row display, real-time display of cumulative batches and cumulative output, number of packages; ◆Adjustable automatic peeling cycle function, keyboard encryption function, data encryption function, clock display function; ◆Equipped with standard RS232 and RS485 interfaces, can be connected to computers and miniature printers. The instrument can print production data statistical reports when connected to a computer. Technical principle This technology realizes the weighing and packaging of lifting bag-type ultra-fine powder materials through the following methods: 1. The packaging bag is clamped at the open end on a bag clamping device, the clamping device is installed on a weighing sensor, and the sensor is installed on a sliding mechanism that can move up and down. The sliding does not affect the weighing measurement of the sensor. 2. The powder material is fed by a single vertical screw feeder with multiple speeds, the feeding speed is fast at first and slow later, when the feeding stops, a valve at the outlet of the screw feeder is closed to completely stop the feeding. 3. The weight of the material in the packaging bag is constantly measured by the weighing instrument, and the lifting action of the mechanism is controlled according to the weight change program by the instrument. Wuxi Zhongyang Packaging Technology Co., Ltd. Address: No. 70 Nankai Road (Hudong Industrial Park), Shuofang Airport Industrial Park, Wuxi City Phone: 0510-82131722 88550806 Fax: 0510-82137653 Contact: Mr. Zhou Mobile: (0)13771089168 QQ: 2432242318 After-sales service: 0510-88550806-648 or 698 E-mail: zhou@zybzjs.com Zip code: 214028 Website: www.zybzjs.com
