Directly supplied PE water supply pipe, fire protection pipe, drainage pipe
Construction Materials-Other Building Materials
Expand
Product Content
Category
Construction Materials-Other Building Materials


There are many types of PE pipes, which can be classified in various ways, mainly as follows:
Based on the production method of the fittings: injection-molded fittings, welded fittings;
Based on construction methods and uses: electric heat fusion fittings, hot melt butt fittings, socket fittings, steel-plastic transition joints;
Based on engineering habits: couplings, elbows, tees, saddle tees, reducers, end caps, flanges, steel-plastic transitions;
Based on the pressure rating of PE pipes, they are mainly categorized into 0.6MPa, 0.8MPa, 1.0MPa, 1.25MPa, and 1.6MPa. The unit MPa is a pressure unit, for example, 0.6MPa means a pressure of 6 kilograms.


Based on the diameter of the PE pipes, they can generally be divided into: 20, 25, 32, 40, 50, 63, 75, 90, 110, 125, 160, 180, 200, 225, 250, 280, 315, 355, 400, 450, 500, 560, 630, 710, 800, 900, 1000, 1200 (mm)

The commonly used PE pipes include PE water supply pipes, PE gas pipes, PE conduit pipes, PE mining pipes, PE corrugated pipes, and more.

Polyethylene gas pipelines have excellent corrosion resistance, impact resistance, good flexibility and sealing, convenient construction and maintenance, a long service life, and can be safely used for over 50 years. They effectively solve the two major problems of traditional pipelines: corrosion and joint leakage, and are widely used for the transportation of various gas media, such as natural gas, liquefied petroleum gas (gaseous), and manufactured gas.

Performance Characteristics

① Corrosion resistance - PE is an inert material that can withstand the erosion of various chemical media without the need for anti-corrosion treatment.

② No leakage - PE uses electric heat fusion connections, hot melt butt connections, and hot melt socket connections, with joint strength higher than that of the pipe itself.

③ High toughness - PE generally has a break elongation rate of over 500%, with strong adaptability to uneven settlement of the pipe base and excellent earthquake resistance.

④ Excellent resistance to slow crack growth (SCG) and rapid crack propagation (RCP)

⑤ Good flexibility, can be coiled, reduces joints, and lowers construction costs

⑥ Low wall friction coefficient, small flow resistance, strong transport capacity

⑦ Can adopt various trenchless methods, greatly facilitating construction and installation

⑧ Low system cost, low maintenance costs, can significantly reduce project costs.

⑨ Long service life, can be safely used for over 50 years under rated temperature and pressure.

⑩ Lightweight, easy to transport and handle.

Application Fields

SDR11 series for natural gas, liquefied petroleum gas (gaseous), manufactured gas, etc.


SDR17.6 series for natural gas

Product Appearance

PE80 - black pipe with yellow stripes or yellow pipe

PE100 - black pipe with orange stripes or orange pipe

Product Classification

Classified by raw materials into PE80 and PE100

Classified by standard dimension ratio into SDR11 and SDR17.6

Classified by crack propagation resistance into traditional pipes and PE100-RC pipes

Product Specifications

dn20mm-dn630mm

Standard length 12m (lengths of 6m, 9m can be provided as per customer requirements)

Pipes with dn≤63mm can be coiled
