Armored Power Cable
1. PVC Insulated Armored Power Cable
1.1 Purpose
This product is suitable for AC 50Hz, rated voltage 0.6/1KV lines, for the purpose of power transmission and distribution.
2. Usage Characteristics
2.1 The rated temperature of the cable conductor is 70℃.
2.2 In case of a short circuit (not exceeding 5 seconds), the temperature of the cable conductor does not exceed 160℃.
2.3 The environmental temperature during cable laying should not be lower than 0℃, and the minimum bending radius should not be less than 10 times the outer diameter of the cable.
3. Model and Name
Model Name
VV22 PVC Insulated PVC Sheathed Steel Tape Armored Power Cable
YJV22 Cross-linked Polyethylene Insulated PVC Sheathed Steel Tape Armored Power Cable
VLV22 PVC Insulated PVC Sheathed Steel Tape Armored Aluminum Core Power Cable
YJLV22 Cross-linked Polyethylene Insulated PVC Sheathed Steel Tape Armored Aluminum Core Power Cable
VV32 PVC Insulated PVC Sheathed Steel Wire Armored Power Cable
YJV32 Cross-linked Polyethylene Insulated PVC Sheathed Steel Wire Armored Power Cable
VLV32
PVC Insulated PVC Sheathed Steel Wire Armored Aluminum Core Power Cable
YJLV32 Cross-linked Polyethylene Insulated PVC Sheathed Steel Wire Armored Aluminum Core Power Cable
