Runshuo PE pipe drainage method

1. Same-floor drainage does not require old-fashioned P-traps and S-traps for water seals, while the traditional bottom drainage method requires each sanitary fixture to have an additional P-trap or S-trap water seal. The old-fashioned P-trap and S-trap are easy to clog, which is a disadvantage of the traditional bottom drainage method. Looking at same-floor drainage with conventional thinking, this is the part that people do not understand about same-floor drainage.

2. The same-floor drainage horizontal pipe is laid inside the same floor, while the traditional bottom drainage horizontal pipe, including its P-trap and S-trap, is laid through the floor slab on the lower floor, occupying the interior space of the lower floor.

3. Once a blockage occurs, the same-floor drainage method achieves the purpose of cleaning and dredging within the same floor, while the traditional bottom drainage method must go to the lower floor to clean and dredge.

4. In the traditional drainage method, when users on the upper floor use sanitary fixtures, obvious noises can be heard on the lower floor, while the same-floor drainage method is almost inaudible.

Personalized design of same-floor drainage system.

When installing PE water pipes, you may encounter various safety issues. So pay attention during installation:

　　1. Must measure the voltage after loading, ground the machine shell to ensure personal safety. Must measure the voltage of the power grid and generator to ensure a voltage of 220V, to prevent machine damage.

　　2. The temperature indicator light of the heating plate must be on (red) to ensure the welding temperature. All objects in contact with the welding end face must be clean to ensure welding quality.

　　3. The safety lock of the milling cutter must be locked during milling to prevent the milling cutter from flying out and injuring people. The pipe clamp must leave enough distance to ensure effective contact of the welding end face.

　　4. The milling chips must be continuous long chips to ensure effective contact of the welding end face. When removing the milling cutter and heating plate, do not touch the end face to prevent uneven burrs and scratches.

　　5. When starting the pumping station, the direction rod should be in the middle to ensure the motor starts without load.

Application areas

PE suction pipes have a competitive advantage in the field of building water supply, and in the fields of gas, industrial water supply and drainage, communications, agricultural irrigation, PE pipes are also growing rapidly. However, the standards and specifications of some fields have not kept up, which has to some extent affected the application and development of PE pipes.
