Brief description:Sheet lithium battery type host is a new type of thermosetting molding plastic, used in transportation, construction, and electrical applications. The BMSJ sheet machine is a production equipment for unsaturated polyester fiberglass reinforced composite material, which consists of adding thickeners, fillers, release agents, and curing agents to polyester resin, impregnating it with fiberglass yarn, and covering both sides with film to form a sandwich structure.
Sheet Lithium Battery HostIntroduction:
The main production is sheet molding compound (SMC), a new type of thermosetting molding plastic, used in transportation, construction, and electrical applications. It is a polyester resin mixed with thickeners, fillers, release agents, and curing agents, impregnated with fiberglass roving, and covered on both sides with film to form a sandwich structure, which is an unsaturated polyester fiberglass reinforced composite material production equipment.
The host machine adopts a web belt for material pressing, with the press body's lifting and lowering using pneumatic form, and the web belt tension also using pneumatic form. The web belt and material trough are made of stainless steel, and all rollers are first ground and then chrome-plated. The winding section uses a torque motor drive, allowing for adjustable winding speed at any time, automatic winding, and pneumatic clamping to save effort and time. The yarn cutting section uses a variable speed motor to achieve stepless speed change, increasing the range of yarn content, with reliable and precise adjustments. The yarn cutting roller adopts a spiral form to reduce noise and improve the service life of the rubber roller and blades. The electrical control part uses central control to meet production needs.
Sheet Lithium Battery Type HostPrecautions for Use:
The temperatures of each section on the plastic sheet production equipment barrel gradually increase from the feeding section to the point where the barrel connects with the forming mold.
2, The mold temperature for forming is slightly higher than the barrel temperature, with a difference of 5-10°C. The temperature at both ends of the mold is slightly higher than the temperature in the middle, also with a difference of 5-10°C.
3. For the sheet entry, the upper surface of the middle roller among the three rollers should be on the same horizontal plane as the lower flat surface of the die lip; the end face of the die lip should be parallel to the centerline of the middle roller, with a distance of 50~100mm.
4. The die lip gap should be slightly less than or equal to the thickness of the sheet product, with the center gap of the die lip being slightly smaller than the gaps at both ends.
5. Note that the surface roughness R of the three rolls should not exceed 0.2 μm. When cleaning the roll surface, do not use a hard steel blade to scrape it; instead, use a copper knife to remove any residue.
6, The roller surface should have some crown; the gap between the three rollers should be equal to or slightly greater than the thickness of the plate.
7. The temperature control of the molding die must be stable. When the temperature is high, the flow rate of the molten material inside the mold increases; when the temperature is low, the flow rate of the molten material inside the mold decreases. Unstable flow rates of the molten material can lead to significant longitudinal thickness variations in the plate (sheet) products.
8. Pay attention to controlling the working surface temperature of the three rolls, with the inlet roll being slightly warmer and the outlet roll slightly cooler. If the roll surface temperature is too high, the sheet will not easily detach from the roll, and horizontal lines may appear on the product's surface; if the temperature is too low, the product's surface will lack luster. Based on these phenomena, the roll surface temperature should be adjusted in a timely manner.
