Brief Description:The fully automatic sheet extrusion machine is a new type of thermosetting molding plastic used in transportation, construction, and electrical applications. The BMSJ sheet machine is a production equipment for unsaturated polyester fiberglass reinforced composite materials, which involves adding thickeners, fillers, release agents, and curing agents to polyester resin, impregnating fiberglass yarn, and covering both sides with film to form a sandwich structure.
Mainly produces sheet molding compounds, which is a new type of thermosetting molding plastic used in transportation, construction, and electrical applications. It is a production equipment for unsaturated polyester fiberglass reinforced composite material, consisting of a polyester resin mixed with thickeners, fillers, release agents, and curing agents, impregnated with fiberglass yarn, and covered on both sides with film to form a sandwich structure.
The main unit adopts a web belt for material pressing, with the lifting and lowering of the pressing body using pneumatic form, and the web belt tension also using pneumatic form. The web belt and material trough are made of stainless steel, and all rollers are first ground and then chrome-plated. The winding section uses a torque motor for driving, allowing the winding speed to be adjusted at any time, with automatic winding and pneumatic clamping, saving effort and time. The yarn cutting section uses a variable speed motor to achieve stepless speed change, increasing the range of yarn content, with reliable and accurate adjustment. The yarn cutting roller adopts a spiral form to reduce noise and improve the service life of the rubber roller and blades. The electrical control part uses central control to meet production requirements.
Precautions for Using Fully Automatic Sheet Extrusion Machine:
The temperatures of each section on the plastic sheet production equipment barrel gradually increase from the feeding section to where the barrel connects with the forming mold.
2. The mold temperature for forming is slightly higher than the barrel temperature, with the difference controlled within 5-10°C. The temperatures at both ends of the mold are slightly higher than the middle, with the difference also controlled within 5-10°C.
3. For the sheet entry, the upper surface of the middle roller among the three rollers should be at the same level as the lower plane of the die lip; the end face of the die lip should be parallel to the centerline of the middle roller, with a distance of 50~100mm.
4. The die lip gap should be slightly less than or equal to the thickness of the sheet product, with the center gap of the die lip being slightly smaller than the gaps at both ends.
5. Note that the surface roughness R of the three rollers should not exceed 0.2 μm. When cleaning the roller surface, do not use a hard steel blade to scrape it; instead, use a copper knife to remove any residue.
6. The roller surface should have some crown; the gap between the three rollers should be equal to or slightly greater than the thickness of the plate.
7. The temperature control of the molding die must be stable. When the temperature is high, the flow rate of the molten material inside the mold increases; when the temperature is low, the flow rate of the molten material decreases. Unstable flow rates of the molten material can lead to large variations in the longitudinal thickness of the sheet (plate) products.
8. Pay attention to controlling the surface temperature of the three rollers, with the inlet roller being slightly warmer and the outlet roller slightly cooler. If the roller surface temperature is too high, the sheet will not easily detach from the roller, and horizontal lines may appear on the product's surface; if the temperature is too low, the product's surface will lack luster. Based on these observations, the roller surface temperature should be adjusted in a timely manner.
