【High Temperature Resistant Protective Sleeve】Basic Description
1.Product Name: High Temperature Resistant Protective Sleeve
2.Product Alias: High Temperature Fire Sleeve, High Temperature Insulation Fire Sleeve, Fireproof Tube, Silicone Glass Fiber Tube, Thermal Insulation Sleeve
3.Product Model:HT-1
4.Type: Insulation Fire Sleeve
5.Material: Silicone Rubber Coated, Alkali-Free Glass Fiber
6.Product Performance: High Temperature Resistance, Fireproof, High Pressure Resistance, Corrosion Resistance, Wear Resistance, Flame Retardant, Insulation, Moisture Proof, Oil Proof
7.Color: Rust Red, Other Colors Available on Custom Order
8.Diameter:6.5mm-130mm
9.Rated Voltage: 7kv--17.7 kv
10.Thickness: 2mm-6mm
11.Fire Resistance Temperature: Continuous Use Temperature260-550°C
Haotian Brand High Temperature Resistant Protective Sleeve Features and Applications
Weather Aging Resistance, Pollution Resistance, Extending Equipment Lifespan
The service life in natural environments can reach decades, maximizing the protection of pipelines, cables, and equipment in these situations, significantly extending their lifespan.
Ozone Resistance, Voltage Resistance, Arc Resistance, Corona Resistance
Due to the surface coating of organic silicone, with a main chain of -Si−O−, bonds exist, making it resistant to decomposition by ultraviolet light and ozone. The High Temperature Resistant Protective Sleeve has excellent electrical insulation properties, with dielectric loss, voltage resistance, arc resistance, corona resistance, volume resistivity, and surface resistivity ranking among the best in insulation materials, and their electrical performance is minimally affected by temperature and frequency. Therefore, they are a stable electrical insulation material widely used in the electronics and electrical industries.
Outstanding High Temperature Resistance
The High Temperature Resistant Protective Sleeve can be continuously exposed to high temperatures of 260℃ without damage, withstand temperatures up to1090℃ for15 to 20 minutes, and endure 1650℃ for15 to 30 seconds, its unique flame retardant properties not only effectively prevent personnel from being burned by high-temperature pipelines, but also significantly save on the cost of thermal energy loss.
Unique Chemical Stability
The high temperature protective sleeve has strong chemical stability, with organic silicone showing no reaction to oil, water, acids, and bases, can be used long-term at 260℃ without aging, because of the surface coating of organic silicone, it is not easily decomposed by ultraviolet light and ozone.
Splash Protection, Multiple Safeguards
In the metallurgy industry, the medium temperature inside electric furnaces is extremely high, easily forming high-temperature splashes (the same goes for electric welding industry), which after cooling and solidifying can form slag on pipelines or cables, causing the rubber outer layer of pipelines or cables to harden and become brittle and fracture. This can damage unprotected equipment and cables. The High Temperature Resistant Protective Sleeve, coated with multiple layers of silicone, achieves multiple safety protections, with high temperature resistance up to 1300 degrees Celsius, effectively blocking splashes of molten iron, molten copper, molten aluminum, and other high-temperature molten materials, preventing damage to surrounding cables and equipment.
Safe and Environmentally Friendly
Alkali-free glass fiber itself has extremely strong tensile strength, will not wrinkle or break, is sulfur resistant, smoke-free, halogen-free, non-toxic, pure oxygen non-flammable, and has good insulation properties. After curing with organic silicone, its safety and environmental performance is further enhanced, effectively protecting the health of workers and reducing the incidence of occupational diseases. Unlike asbestos products, which pose significant hazards to human health and the environment.
