The VICKERS proportional amplifier is a controller with selectable control modes, including Proportional (P) control, Integral (I) control, and Proportional-Integral (PI) control. It features three-channel input, voltage or current output configurable via dip switches, powered by 24VDC, and designed for board installation. The output current is selectable, and the vibration amplitude is adjustable. The performance parameters are as follows: Power Supply 24V (22~28V); 75mA@24V, 200mA@100mA load Combined Air Supply Unit Plastic Bending Testing Machine Woven Bag Tension Tester
Input 1 Vpp≤95V, built-in adjustable attenuator; switch selectable 55ms filter
Input 2 4-20mA or 0~±10V
Feedback Input 4-20mA or 0~±10V
Feedback Gain 1~10
Proportional Gain 1~20 Environmental Electric Heating Mantle FE30K Variable Speed Multi-purpose Oscillator
Integral Time 1~45/s
Output Current ±5mA~±100 mA, large load resistance: 11V/I (Amp) - 39Ω
Voltage ±10V, small load 100Ω, vibration signal frequency 200Hz, ±10%In
Dimensions 100mm×108mm×45mm for user-configurable input and feedback signals, designed for board installation, compact size, powered by 24V DC, output current customizable according to customer needs, with vibration signal output, capable of supplying ±15V DC to external sensors. Performance parameters are as follows: VICKERS Proportional Amplifier Cone-Shank Twist Drill High-Pressure Reactor Vertical Flow Purification Workbench
Power Supply DC24V (Min 18V, Max 36V), 5W
Output Power DC±15V +5V
Gain K1=1.52
K2=1
K3=1~2.4mA/V
Input Impedance 33kΩ
Input Command 4～20mA or 1～5V or ±10V
Feedback Command 4～20mA or 1～5V or ±10V
Vibration Amplitude Frequency f=200Hz, Vp-p≤30%In
Maximum Output Current Ip≤2 In
Nonlinear Distortion ≤±1%
Dimensions 100mm×113mm×22mm
