Vertical Machining Center Features
1. High Rigidity Structure
a. All large components of the vertical machining center are constructed with a closed box shape, featuring thick walls and multiple ribs, made from gray cast iron resin sand casting, treated through multiple stress relief processes.
b. The VMC500 high-speed precision drilling vertical machining center uses linear rolling guides, providing very high positioning speed and accuracy. The bed saddle exhibits no sagging throughout its entire travel.
2. Excellent Manufacturing
The VMC500 high-speed precision drilling vertical machining center has its motion coordinate positioning accuracy and repeated positioning accuracy verified during factory inspection, utilizing scientific means and reliable data.
3. High Precision and Rigid Spindle
The spindle's bearings in the vertical machining center utilize a set of preloaded high-precision angular contact ball bearings, and the BT40 bearing configuration provides the spindle with high rigidity and accuracy.
b. It employs a high-torque spindle motor with very high output power.
c. The spindle's working accuracy is very stable.
4. Very High Positioning Accuracy
The three-coordinate ball screw is directly coupled with an elastic coupling and AC servo motor, combined with special bearing supports for the screw. It undergoes pre-stretching before leaving the factory to ensure that the feed system is free of backlash, has high rigidity, and stable work characteristics.
5. Efficient and Reliable Automatic Tool Changing Device
FE30K Variable Speed Multi-Use Oscillator Taper Shank Twist Drill
a. It adopts a umbrella-style automatic tool changer that allows for rapid, smooth, and reliable tool exchanges.
b. The tool magazine can be configured to hold 8, 10, or 12 BT30 type cutting tools.
c. The tool changing system has good maintainability.
High-Pressure Reaction Kettle Vertical Flow Purification Workbench
6. Uses Highly Reliable Supporting Components
7. Mechatronics Design
Fully AC digital servo. Good control performance, easy maintenance, and simple operation. It can achieve bidirectional compensation for coordinate positioning accuracy.
8. Designed to Maximize Customer Requirements
a. Each vertical machining center can provide a complete set of automatic hydraulic presses, fully realizing a turnkey project.
b. The CNC system and supporting components can be configured according to user requirements.
