Thread Specifications: Metric Threads, German Threads, American Threads, British Threads.
Product Material: nuts, pillars, clamping jaws, pressure heads and other parts are made of environmentally friendly nylon PA6, washers are made of aging-resistant silicone rubber rings, and clamping rings are made of oil-resistant rubber.
Fire Rating: UL94V-2.
Protection Level: Within the specified bayonet range, tighten the waterproof gasket and clamping ring to tighten the pressure head, achieving IP67.
Color Varieties: Light grey, black.
Instructions: Thread the main body onto the motherboard first, then tighten with a nut, pass the cable through the pressure head, tighten the pressure head to secure it.
Operating Temperature: Static -40°C to 85°C.
Product Features: The design of the integrated clamping jaw and clamping ring, combined with the assembly of the pressure head, saves time and is convenient, with a wide range of clamping cables, strong tensile strength, waterproof, dustproof, salt-resistant, acid and alkali resistant, alcohol, oil, grease, and general solvent resistant. Used for fixing, protecting, and sealing dust and water at the cable outlet end.
More Options: Various range of clamping rings available, notify for replacement with aging-resistant silicone rubber material when high environmental rubber is required for outdoor use.
