Stage Pressure Line Board Rubber Wire Trough Board Manufacturer Rubber Wire Trough Board Installation
Product features:
1. The product is made of high-strength rubber,
2. Sturdy and durable, pressure-resistant, long life, no noise, good shock absorption, good pressure resistance;
3. Special technology ensures long-lasting color, bright colors, not easy to fade;
4. Clear colors, obvious signs, high visibility in both day and night;
5. Mainly suitable for cable crossing on roads, temporary construction or stage use, good pressure resistance, safe and convenient, and beautiful appearance;
6. Simple installation, can be used repeatedly;
7. Excellent wear resistance
8. Anti-slip surface texture on the surface layer
9. Resistant to oil and many solvents
10. Working temperature range: -15℃ to 65℃
11. Perfect product accessories: elbow
12. Safety warning signs synthetic cover surface
13. The bottom special anti-slip design rubber stage performance cable trough board, no need to damage the ground for installation
14. High pressure bearing capacity, suitable for heavy trucks, forklifts, generators, OB vans, container trucks
Type A products:
Two troughs: 1000*250*45mm Trough diameter: 30*25mm Weight: 7kg
Medium two troughs: 800*430*65mm Trough diameter: 50*50mm Weight: 12.5 kg
Large two troughs: 660*580*105mm Trough diameter: 90*90mm Weight: 19 kg
Three troughs: 1000*345*50mm Trough diameter: 30*30mm Weight: 12 kg
Three troughs: 800*430*50mm Trough diameter: 30*30mm Weight: 12 kg
Large three troughs: 800*520*85mm Trough diameter: 65*65mm Weight: 14.5 kg
Four troughs: 800*500*65mm Trough diameter: 50*50mm Weight: 16.5 kg
Five troughs: 800*500*50mm Trough diameter: 50*50mm Weight: 12.5 kg
Stage Pressure Line Board Rubber Wire Trough Board Manufacturer Rubber Wire Trough Board Installation
Type B products:
2-hole trough board XC-B-01 100cm×50cm×7.5cm Single trough hole diameter: 55×65mm
3-hole trough board XC-B-02 100cm×31cm×5.5cm Single trough hole diameter: 35×35mm
4-hole trough board XC-B-03 77cm×48.5cm×6.5cm Single trough hole diameter: 40×40mm
3-hole trough board XC-B-04 90cm×60cm×7.5cm Single trough hole diameter: 50×60mm
5-hole trough board XC-B-05 90cm×60cm×7.5cm Single trough hole diameter: 35×50mm
Type C products:
2-hole trough board XC-C-01 100cm×25cm×4.5cm Single trough hole diameter: 32×35mm
3-hole trough board XC-C-02 90cm×50cm×7.5cm Single trough hole diameter: 50×55mm
5-hole trough board XC-C-03 90cm×50cm×5cm Single trough hole diameter: 32×35mm
Warm tips: Yilan brand wire trough board provides 1-hole, 2-hole, 3-hole, 4-hole, 5-hole model specifications of products,
sincerely look forward to your call for negotiation.
Installation method:
1. Place the wire trough board where wiring is needed, connect each piece, put the wire in, cover it, and the road for placing the wire trough board,
or exhibition hall site, etc., as flat as possible. There are one-slot, two-slot, three-slot, four-slot, five-slot wire trough boards, for example, if there are two wires,
choose a two-hole wire trough board
2. The installation is relatively convenient, usually using standard block arbitrary combination method and internal expansion bolts, firmly fix it on the ground with screws, install it firmly, stable and reliable,
it will not loosen when hit by a vehicle.
