The ZR5221-69 Multi-mode 4G Broadband Router from Zhiliang IoT is an IoT wireless communication router that uses 5 modes and 13 frequencies (TDD/TDScdma/FDD/WCDMA/GSM) or 7 modes and 15 frequencies (TDD/TDScdma/FDD/WCDMA/GSM/EVDO/CDMA 1X) to provide users with convenient and fast network transmission capabilities through mobile broadband networks.
This series of products adopts a high-performance industrial-grade 32-bit communication processor, supported by an embedded real-time operating system, to provide users with a secure, high-speed, and stable 3G/4G wireless routing network, featuring 4 LAN ports, 1 WAN port, 485/232, and Wi-Fi interfaces.
This series of products has been widely applied in various industries including finance, postal services, smart grids, intelligent transportation, environmental monitoring, fire monitoring, security monitoring, water monitoring, public safety, advertising, industrial control, earthquake monitoring, meteorological monitoring, and instrument monitoring.
Product Features
Industrial-grade design
? Utilizes high-performance industrial-grade wireless modules
? Utilizes high-performance industrial-grade 32-bit processors
? Supports low power modes, including sleep mode and scheduled on/off modes
? Utilizes cold-rolled steel casing
? Power supply: +7.5V~32V DC (max 36V)
? Protection level: IP34 (can be treated to IP51)
Network Characteristics
? Port traffic detection
? Link real-time monitoring
? Multiple VPN protocols (PPTP, L2TP, IPSec, VPN)
? Serial DTU function support
? Supports on-demand dialing (voice, SMS, or data trigger)
? Supports UPnP
? Transmission rates up to 150Mbps~300Mbps
Stable and Reliable
? Uses software and hardware watchdogs and multi-level link detection mechanisms to provide automatic fault detection and recovery capabilities, ensuring stable and reliable operation of the equipment
? Multiple self-check mechanisms for devices to ensure smooth links and alarms
? ESD protection on all interfaces to prevent electrostatic shock
? Includes wireless network signal indicator lights, displaying three levels of signal strength
Remote Management
? Supports remote parameter configuration
? Supports remote parameter backup
? Supports remote reboot and log inquiry
? Supports local and remote platform firmware device upgrades
? Supports online monitoring of devices and real-time traffic monitoring
? Supports SMS wake-up mode
Functional Features
? Simultaneously supports 4G (FDD and TDD) LTE networks, backward compatible with HSUPA/EVDO/GPRS various network standards
? Supports 1 WAN + 4 LAN, providing standard RS-232 / RS-485 interfaces
? Supports Wi-Fi, compatible with IEEE802.11b/g/n
? Supports wired and wireless network backup
? Supports hardware WDT, providing a disconnection prevention mechanism to ensure data
Terminal Online
? Supports multiple VPN protocols including PPTP, L2TP, GRE
? Supports SNMP management protocol
? Supports Wi-Fi forced advertising push functionality
? Supports DHCP, DDNS, firewall, NAT, and DMZ host functionalities
? Supports ICMP, TCP, UDP, Telnet, FTP, HTTP, HTTPS, and other network protocols
? Anti-theft and anti-drop SIM/UIM card design
Extended Functions
? Supports dual-mode dual-SIM. Adopts a dual-mode dual-SIM design, working simultaneously; SIM card switching takes only 5-6 seconds and can differentiate based on signal strength or primary/secondary modes, supports wired to Wi-Fi, 4G to Wi-Fi, and wired/wireless dual backup [optional]
? Supports single-mode dual-SIM [optional]
? Supports GPS/Beidou positioning for centralized location management and maintenance of devices [optional]
? Supports internal storage expansion, 2GB-32GB [optional]
M2M Management Cloud Platform for Unified Centralized Management
? Device fault alarms to enhance online rates of devices in remote areas
? Operational upgrades and automatic fault recovery to ensure smooth transmission pipelines, enhancing scalable management
? Multiple encryption technologies to ensure the security of data in communication links
? Remote management and maintenance of devices to reduce operation and maintenance costs and improve efficiency
? Supports network management functionalities, controllable and manageable traffic, reducing operation and maintenance costs
? Automatically generates business statistical reports to provide strong evidence for operational decision-making
Product Specifications
Wireless Parameters
Wireless Module: Industrial-grade wireless module
Standards and Frequency Bands: FDD-LTE (Band1/3/5)
TDD-LTE (Band38/39/40/41), TD-SCDMA (Band34, Band39)
HSPA (900/2100MHz)/ GSM850/900/1800/1900MHz
EV-DO & CDMA 1X (800MHz)
Theoretical Bandwidth: FDD: 100/50Mbps, TDD: 61/18Mbps
Transmission Power: <24dBm
Receiving Sensitivity: <-109dBm
WIFI Wireless Parameters
Standards and Bandwidth: Supports IEEE802.11b/g/n standards, with a maximum rate of 150Mbps / 300Mbps [optional]
Security Encryption: Supports multiple encryption methods such as WEP, WPA, WPA2, and optional WPS functionality
Transmission Power: 16-17dBm (11g), 18-20dBm (11b), 15dBm (11n)
Receiving Sensitivity: <-72dBm@54Mbps
Interface Type
LAN: 4 Ethernet interfaces (RJ45 socket), adaptive MDI/MDIX, built-in electromagnetic isolation protection
WAN: 1 WAN port, adaptive MDI/MDIX, built-in electromagnetic isolation protection
Industrial Interfaces: 1 communication RS485/RS232 interface, suitable for collection devices equipped with RS485/232 interfaces
Indicator Lights: Includes “WAN”, 4 X “LAN”, “WLAN”, “NET” indicator lights, with the “NET” light being a tri-color light
(Red: Poor network signal; Orange: Average network signal; Green: Good network signal)
Antenna Interface: 3 standard SMA antenna interfaces (WIFI/GPS and 2 x 3G), characteristic impedance 50 ohms
SIM/UIM Interface: SIM/UIM card engineering cover to protect the card from falling out. 1.8V/3V automatic detection
Power Interface: 7.5V~32V (standard DC12V/1.5A), built-in power instantaneous overvoltage protection
Reset Button: This button can restore the Router's parameter configuration to factory settings
Power Supply
? Standard Power: DC 12V/1.5A
Appearance Features
? Casing: Aluminum alloy casing
? Dimensions: 150×102×25.5mm
? Weight: Approximately 530g
Other Parameters
? CPU: MIPS32 74K Core. 533MHz/560DMIPs
? Flash/RAM: 64Mb / 256Mb
? Operating Temperature: -30~+75℃
? Storage Temperature: -40~+85℃
? Relative Humidity: < 95% non-condensing
