Shielded Control Cable
1. Product Features and Applications
Copper core PVC insulated PVC sheathed copper wire braided shielded control cable is suitable for control, monitoring circuits, and protection lines in occasions with AC rated voltage U0/U 450/750V and below, serving as control wiring between electrical equipment.
The main feature of flame-retardant control cables is that they are not easily ignited or, if ignited, the combustion is limited to a certain range, suitable for occasions with high requirements for flame-retardant performance.
The main feature of fire-resistant control cables is that besides being able to transmit power under normal working conditions, the cable can still maintain normal operation for a certain period during combustion, suitable for occasions with requirements for fire-resistance characteristics.
2. Product Standards
This product is produced according to the GB9330-88 standard, and can also be produced according to other standards requested by users.
The flame-retardant type cable, in addition to the above standards, has its flame-retardant performance categorized into three different flame-retardant classes A, B, and C according to GB12666.5 or IEC332-3 standards, with Class A having superior flame-retardant performance, allowing users to choose based on their needs.
The fire-resistant type cable's fire resistance performance is categorized into two different fire resistance classes A and B (950°C-1000°C for 90 minutes, 750°C-800°C for 90 minutes) according to GB12666.6 standards, allowing users to choose based on usage scenarios and requirements.
3. Product Models
1. Ordinary Type Cable Models
KVVP - Copper core PVC insulated PVC sheathed copper wire braided shielded control cable
KVVP2 - Copper core PVC insulated PVC sheathed copper tape shielded control cable
KVVP2-22 - Copper core PVC insulated PVC sheathed copper tape shielded steel tape armored control cable
