Selection of Wiring Type
Select the appropriate model of ultrasonic level meter based on the actual measuring range.
If the liquid under measurement fluctuates significantly, please choose a model with a larger range level.
The effective measurement range for solid material level measurement is 1/2 to 2/3 of the liquid level range.
Power Supply TypeSoft and Hard Sealed Butterfly Valve Class 100 Laminar Flow Ward Extended Twist Drill Temperature and Pressure Calibration System Waterproof Membrane Tensile Testing Machine
DC24V Power Supply:
The power supply current capacity for the streamlined series should be no less than 60mA.
The power supply current capacity for the standard series should be no less than 80mA.
AC220V Power Supply:Sulfur Variation Tester Ring Stiffness Testing Machine Crude Oil Water Content Analyzer
The power supply current capacity should be no less than 50mA.
Container Installation Conditions
Closed Container:
For a range below 8m, a flange with a diameter of DN65 or larger is required on the container, with no specific requirements for the length of the connecting pipe below the flange.
For 10m and 12m ranges, a flange with a diameter of DN80 or larger is required on the container, with the connecting pipe length below the flange being less than 150mm.
For a 15m range, a flange with a diameter of DN150 or larger is required on the container, with the connecting pipe length below the flange being less than 150mm.
For 20m, 30m, and 40m ranges, a flange with a diameter of DN200 or larger is required on the container, with the connecting pipe length below the flange being less than 200mm.
Open Container:Ground Wire Group DC Resistance Tester Taper Shank Twist Drill Senbon Anti-Explosion Speed Adjustable Multi-Use Oscillator Digital Temperature Control Electric Heating Jacket Vacuum and Dough Machine
For a range below 8m, an installation port with a diameter of 65mm or larger is required on the container.
For 10m and 12m ranges, an installation port with a diameter of 80mm or larger is required on the container, with the port thickness being less than 150mm.
For a 15m range, an installation port with a diameter of 150mm or larger is required on the container, with the port thickness being less than 150mm.
For 20m, 30m, and 40m ranges, an installation port with a diameter of 200mm or larger is required on the container, with the port thickness being less than 200mm.
Open Pool:Mettler Agency LMI Milton Roy Slant Tool CNC Lathe
Installation bracket is required
