Safety Valve / Back Pressure Valve for Metering Pump Accessories

Detailed information about metering pump accessories: safety valve/backpressure valve:

Backpressure Valve: Used to prevent liquid from flowing by gravity or siphoning, at which point the backpressure valve can reduce the flow and pressure fluctuations caused by siphoning.
Safety Valve: When the system or pipeline pressure is too high, it can promptly release pressure, protecting the pump and allowing for liquid recovery. It also serves as a pressure relief valve and is an essential valve for pipeline systems, ensuring that the system does not operate under excessive pressure, thus protecting the pipeline and equipment safety.
Common materials: PVC, SUS304, SUS316, PVDF, etc.
How to select a backpressure valve for industrial pipelines?
Backpressure valves generally have two purposes:
1: The backpressure valve is used to prevent liquid from flowing by gravity (or siphoning). In this case, it is generally selected to be greater than the liquid's own pressure. For example, to prevent liquid from flowing out of a 2-meter high tank, a backpressure valve with a pressure greater than 0.02MPa can be selected, typically using 0.1MPa.
2: The backpressure valve is used to stabilize the flow of the pump. For certain pumps where the flow varies significantly with pressure, a backpressure valve can be set at the pump outlet to stabilize the output flow. In this case, the pressure of the backpressure valve is generally chosen to be equal to or slightly less than the actual operating pressure of the pump.
The check valve on the outlet pipeline is used to prevent liquid backflow, while the backpressure valve is used to maintain a constant pressure at the pump outlet.
When purchasing a backpressure valve, please provide the following data:
1. Diameter of the backpressure valve
2. Desired pressure setting
3. Required material
It is also helpful to inform about the conveyed medium, temperature, and flow rate.
