Rubber Cable Protection Board Rubber Cable Tray Shanghai Rubber Cable Tray
Since the launch of the self-designed cable channel speed bump product, counterfeit products have started to appear in the market, produced using inferior recycled plastics. These products do not meet electrical engineering technical requirements, seriously lacking in insulation, flame retardancy, and impact resistance performance indicators, posing risks to personal and property safety, and severely infringing on consumer rights.
Shanghai Yilan Traffic Facilities Co., Ltd. products are popular both domestically and internationally, with more than 10 sales outlets in major cities across the country. With the company's strong strength and consistent industry praise, we successfully partnered during the Guangzhou Asian Games. Our company’s “Yilan brand” cable channels are designated brand suppliers for electrical wiring products. We look forward to cooperating with you to create brilliance together!
Our company specializes in manufacturing rubber cable protection boards, cable channels, stage cable trays, performance cable boards, electrical wire channels, rubber bridge plates, PVC cable channels, and cable bridge plates. Our reputation is built on quality; the cable protection boards we provide are designed to offer an effective cable management system to ensure safety while you work, making your business operations smoother.
A Class Straight Boards:
Medium Dual Channel Specifications: 1000*450*70mm Channel Diameter: 50*50mm Weight: 13 kg
Dual Channel Specifications: 800*300*45mm Channel Diameter: 30*25mm Weight: 7 kg
Medium Dual Channel Specifications: 800*430*65mm Channel Diameter: 50*50mm Weight: 12.5 kg
Large Dual Channel Specifications: 660*580*105mm Channel Diameter: 90*90mm Weight: 19 kg
Triple Channel Specifications: 1000*345*50mm Channel Diameter: 30*30mm Weight: 12 kg
Triple Channel Specifications: 800*430*50mm Channel Diameter: 30*30mm Weight: 12 kg
Large Triple Channel Specifications: 800*520*85mm Channel Diameter: 65*65mm Weight: 14.5 kg
Quad Channel Specifications: 800*500*65mm Channel Diameter: 50*50mm Weight: 16.5 kg
Penta Channel Specifications: 800*500*50mm Channel Diameter: 30*30mm Weight: 12.5 kg
A Class straight boards can be equipped with 90° corner and three-way corner.
Rubber Cable Protection Board Rubber Cable Tray Shanghai Rubber Cable Tray
Triple Channel Specifications: 900*500*85mm Channel Diameter: 70*65mm Weight: 15 kg
Quad Channel Specifications: 900*500*60mm Channel Diameter: 40*45mm Weight: 15 kg
Penta Channel Specifications: 900*500*50mm Channel Diameter: 30*40mm Weight: 14 kg
Medium Single Channel Specifications: 1000*260*70mm Channel Diameter: 50*70mm Weight: 8.5 kg
Large Single Channel Specifications: 1000*580*120mm Channel Diameter: 125*100mm Weight: 22 kg
Product Function and Usage
Used for stage lighting wiring, shopping mall wiring, plaza wiring, engineering departments, exhibition companies, electric companies construction wiring, community road wiring, it is an indispensable choice for power supply safety protection equipment in many stages, studios, outdoor performance venues, cultural groups, ensuring safety during wiring. Excellent safety performance, aging resistance, insulation and flame retardancy, can bear up to 60 tons, with a long service life!
The above are some of the cable channels produced by our company. The appropriate channel selection should be based on the diameter and quantity of the cables. For details, please consult the sales manager.
Company Statement: Defective cable channels are never allowed to leave the factory, strict quality control.
