Rubber Cable Protector Rental - Shijiazhuang Rubber Cable Protector
If you encounter difficulties with cable crossing and wiring, please contact us. The cable crossing board increases safety, while protecting your safety and the cables from being crushed or damaged. The cable conduits withstand heavy traffic while remaining flexible and easy to adjust to any required size. They can also be adjusted for uneven ground surfaces. Our products are specially designed to prevent slipping when the cables cross the ramp, featuring high load-bearing capacity, crush resistance, and reusability.
Class A Straight Board:
Medium Double Slot Specifications: 1000*450*70mm Slot Diameter: 50*50mm Weight: 13 kg
Double Slot Specifications: 800*300*45mm Slot Diameter: 30*25mm Weight: 7 kg
Medium Double Slot Specifications: 800*430*65mm Slot Diameter: 50*50mm Weight: 12.5 kg
Large Double Slot Specifications: 660*580*105mm Slot Diameter: 90*90mm Weight: 19 kg
Triple Slot Specifications: 1000*345*50mm Slot Diameter: 30*30mm Weight: 12 kg
Triple Slot Specifications: 800*430*50mm Slot Diameter: 30*30mm Weight: 12 kg
Large Triple Slot Specifications: 800*520*85mm Slot Diameter: 65*65mm Weight: 14.5 kg
Quadruple Slot Specifications: 800*500*65mm Slot Diameter: 50*50mm Weight: 16.5 kg
Quintuple Slot Specifications: 800*500*50mm Slot Diameter: 30*30mm Weight: 12.5 kg
All Class A straight boards can be equipped with 90° corners and T-junction corners.
Class B Straight Board:
3-Slot 1000mm*310mm*55mm (3-Slot) Hole Diameter: 35x35mm
3-Slot 900mm*500mm*75mm (3-Slot) Hole Diameter: 55x65mm
4-Slot 770mm*485mm*65mm (4-Slot) Hole Diameter: 40x40mm
5-Slot 900mm*500mm*50mm (5-Slot) Hole Diameter: 32x35mm
2-Slot 900mm*620mm*100mm (2-Slot) Hole Diameter: 80x90mm
Class C Straight Board:
Small Double Slot Specifications: 1000*250*50mm Slot Diameter: 32*35mm Weight: 7 kg
Triple Slot Specifications: 1000*300*50mm Slot Diameter: 35*32mm Weight: 9 kg
Large Double Slot Specifications: 900*580*90mm Slot Diameter: 80*95mm Weight: 22 kg
Triple Slot Specifications: 900*500*85mm Slot Diameter: 70*65mm Weight: 15 kg
Quadruple Slot Specifications: 900*500*60mm Slot Diameter: 40*45mm Weight: 15 kg
Quintuple Slot Specifications: 900*500*50mm Slot Diameter: 30*40mm Weight: 14 kg
Medium Single Slot Specifications: 1000*260*70mm Slot Diameter: 50*70mm Weight: 8.5 kg
Large Single Slot Specifications: 1000*580*120mm Slot Diameter: 125*100mm Weight: 22 kg
