Jieli synthetic resin tiles are primarily made from polyvinyl chloride resin (PVC), which undergoes high-temperature plasticization, extrusion to a specified thickness, and then cooling and shaping. Asa resin tiles leverage the inherent resistance of PVC chemical materials to chemical corrosion, supplemented by various chemical materials to achieve resistance to severe cold, UV radiation, and aging. Additionally, the high weather-resistant Asa resin selected for the surface of the factory anti-corrosion tiles is dense and water-resistant, eliminating the problem of microporous water infiltration. The anti-corrosion tiles have a large single sheet area, minimal roof seams, and tightly bonded overlaps, resulting in excellent self-waterproofing performance. The price of synthetic resin tiles is determined by their specifications, materials, and thickness; online prices are for reference only. Customization is available according to different customer needs, with nationwide direct sales. For inquiries, please contact 0535-3490877 or 13589772720, Manager Qin.
Corrosion-resistant and good waterproofing
Jieli synthetic resin tiles can withstand long-term corrosion from various chemical substances such as acids, alkalis, and salts. Tests show no chemical reaction after immersion in salt, alkali, and acids below 60% concentration for 24 hours. The high weather-resistant resin used in Jieli synthetic resin tiles is dense and water-resistant, preventing microporous water infiltration. The large single sheet area and minimal roof seams, along with tightly bonded overlaps, ensure outstanding waterproof performance.
Impact-resistant and low-temperature resistant
Physical tests on Jieli synthetic resin tiles show that a 1-kilogram steel ball dropped freely from a height of 2 meters onto the tile surface does not produce cracks. Even after 10 impacts at low temperatures, the product remains undamaged. After 10 freeze-thaw cycles, there are no signs of hollowing, bubbling, peeling, or cracking.
Durable colors
Jieli synthetic resin tiles use ultra-high weather-resistant engineering resin produced by ATOGLAS in France as the surface material, which exhibits extraordinary durability in natural environments. Even when exposed to UV rays, humidity, high, and low temperatures for extended periods, it maintains color stability. Tests in outdoor environments with strong sunlight, such as Arizona and Florida, demonstrate that the product can ensure a △E ≤ 5 color change for up to 10 years.
Thermal insulation and soundproofing
The thermal conductivity of Jieli synthetic resin tiles is 0.325 W/m.k, which is about 1/3 of clay tiles, 1/5 of 10mm thick cement tiles, and 1/2000 of 0.5mm thick color steel tiles. Without considering additional insulation layers, the thermal insulation performance of Jieli synthetic resin tiles can still achieve ideal results. Acoustic measurements indicate that Jieli synthetic resin tiles effectively absorb sound during heavy rain, hail, and strong winds.
Volume stability and load resistance
The expansion coefficient of Jieli synthetic resin tiles is 4.93 × 10^-5 (1/°C). The tile design features bidirectional stretching capability, allowing it to accommodate significant temperature variations without compromising geometric stability. Jieli synthetic resin tiles also exhibit excellent load-bearing capacity. According to tests conducted by the Shandong Building Materials and Components Quality Supervision Station, when supported at a distance of 750mm and subjected to a uniform load of 150kg, the tiles showed no signs of damage.
Lightweight and flame-retardant
Jieli synthetic resin tiles weigh 6kg per square meter, making them lightweight structural materials that effectively reduce the load on buildings and save on structural material usage. They are also easy to handle and install, lowering construction costs. The main structural material of Jieli synthetic resin tiles is polyvinyl chloride resin, whose chemical properties contribute to its flame-retardant characteristics. Tests conducted by national fire safety authorities indicate that the fire performance meets B1 grade standards.
Environmentally friendly and energy-saving
Jieli synthetic resin tiles have obtained the "China Environmental Labeling Product Certification." They have been assessed by the National Ministry of Construction Science and Technology Development Center for their environmental protection, energy-saving, and recyclability, making them a new type of building material product that is currently strongly promoted and supported in China for being "environmentally friendly and energy-efficient."
