The screw is designed with special mixing function and high plasticizing capacity, ensuring the plastic is melted, the color is uniform, and the extrusion output is high.
The coat hanger type die adopts a special double-throttle design, making the thickness adjustment of the sheet more accurate.
The temperature control of ±1℃ can precisely control the plasticizing process and the thickness and flatness of the sheet.
The forming roller platform adopts a vertical or 45° inclined layout, which can be freely lifted and lowered, providing more options during the operation of thick and thin sheets, improving the quality of the sheets.
The forming roller loop cooling system, in conjunction with the mold temperature controller, precisely controls the temperature of the press rollers, ensuring uniform sheet thickness.
The slitter accurately cuts the sheet length and quantity.
The winding table device uses a high-grade torque motor, combined with four-axis automatic tension control, allowing for adjustable speed and winding tension to achieve flat winding of thin sheets. With the slitting device, the desired product width can be freely set. The machine is equipped with an automatic meter counter to set the product length.
