Brief Description:Plastic industry pelletizing machines are mainly used for processing waste plastic films (industrial packaging films, agricultural mulch films, greenhouse films, beer packaging, shopping bags, etc.), woven bags, agricultural convenience bags, basins, buckets, beverage bottles, furniture, and daily necessities. They are suitable for most common types of waste plastics and are widely used and well-received in the waste plastic recycling industry as a versatile plastic recycling and processing machine.
Plastic industry pelletizerStructural Composition
The plastic pelletizer consists of a base, left and right side panels, an electric motor, a transmission system, a feed roller, a rotary cutter (strip cutter), a pelletizing knife, a sieve bucket, and other components. The left and right side panels are placed on the upper part of the base, with the transmission system, feed roller, rotary cutter, and pelletizing knife installed within the side panels, while the motor and sieve bucket are mounted inside the base.
Transmission mechanism: Composed of pulleys, sprockets, and a series of gears, it transmits the motor's rotation to the feeding roller, cutting roller, pelletizing knife, and sieve bucket to accomplish various motions. The transmission relationship is shown in the transmission system diagram.
Features：
All recycled materials can be processed for production without needing to be spin-dried or dried by baking or sun exposure after sorting and crushing, suitable for both wet and dry use.
2. From raw material crushing, washing, feeding to pelletizing, the entire process is automated.
3. Fully utilize the high-pressure friction continuous heating system for automatic production heating, avoiding continuous heating and saving electricity.
4. It adopts a split-type fully automatic power distribution system to ensure the safe and normal operation of the motor.
5. Both the screw and barrel are made of imported high-strength, high-quality carbon steel, ensuring durability and longevity.
6. The machine has an attractive and elegant appearance. It can be painted in colors according to customer requirements.
Plastic industry pelletizerPrecautions:
When the operator is feeding material, they must ensure no foreign objects enter the material and control the temperature properly.
2. If the material does not form strips and sticks to the die head when the machine is first turned on, it is due to the die head temperature being too high. Once it cools down slightly, it will function normally. In most cases, there is no need to stop the machine.
3. The water temperature should generally be between 50-60°C. If it is too low, the strands may break; if it is too high, they may stick together. When starting up, half of the water added should be hot water. If this is not possible, manually feed the material into the pelletizer for a while until the water temperature rises, then let it automatically pelletize to avoid strand breakage. Once the water temperature exceeds 60°C, add cold water to the circulation to maintain the temperature.
4. During pelletizing, the strands must be evenly pulled before entering the roller, otherwise it will damage the pelletizer. If material is violently spewing out from the vent hole, it indicates that impurities have clogged the filter screen. At this point, the machine must be stopped immediately to replace the screen, which can be selected with a mesh size of 40 to 60.
