Plastic Butterfly Valve Model▲PVC Plastic Butterfly Valve Model▲CPVC Plastic Butterfly Valve Model

Construction Materials-Other Building Materials
Expand

Product Content

Category
Construction Materials-Other Building Materials
Plastic Butterfly Valve Description D71X-10S/ Plastic Turbine Butterfly Valve D371X-10S

PVC Plastic Anti-corrosion Butterfly Valve/ Plastic Butterfly Valve/ Anti-corrosion Butterfly Valve/ Plastic Wafer Butterfly Valve/ Valve, PVC Plastic Butterfly Valve Size: DN50--DN200 MM (Inch: 2'--8'), PVC Anti-corrosion Butterfly Valve Pipe Diameter: 63 MM--225 MM. PVC Butterfly Valve Material: Valve Body: PVC, Valve Plate: PP, Valve Stem: 45# Carbon Steel, Handle: PVC, Valve Seat: NBR, TPE, EPDM, FPM (VitonA), Positioning Block: PVC. PVC Butterfly Valve Pressure: PN6--PN10 (PN0.6--PN1.0Mpa). PVC Butterfly Valve Working Temperature: 0--60 degrees. PVC Butterfly Valve Ambient Temperature: -10--+60 degrees. PVC Butterfly Valve Corrosion Resistance, Low Flow Loss, Small Space Occupation. The platform above the PVC butterfly valve is designed to be able to install a driver or electric motor. The double seal valve shaft of the PVC butterfly valve isolates the medium contact parts. Seat Temperature Range: NR (Natural Rubber) -20+82°, EPDM (Ethylene Propylene Diene Monomer) -40+125°, FPM (Viton A) (Fluoroelastomer) -23+160°. Application Range: The product can be widely used in industrial and civil construction, tap water, farmland irrigation, chemical industry, pharmaceuticals, aquaculture, aquariums, sewage treatment, ships and other industries. Outstanding Features: Advanced design, small switch torque, strong sealing performance. The product is environmentally friendly, has good acid and alkali resistance, and corrosion resistance. It has the advantages of abrasion resistance, no scar, light weight, easy installation and disassembly, easy maintenance, and long service life, replacing metal butterfly valves.

I still remember the time when I was a factory maintenance worker. Some of the raw materials produced by the factory were more corrosive. At first, some steel pipes coated with anti-corrosive materials were used. Of course, the effect of the treated ones was much better than the ordinary transportation pipelines. However, the effect was only a short-term solution. In real life, the ones that can play a role in anti-corrosion and are relatively affordable should be plastic ethylene and the like. The parts that are easily corroded should be considered as part of the valve. Some parts that can be rotated are easily stuck together after being eroded by corrosive substances. As a senior pipeline maintenance worker, I am quite familiar with these. It may need to be replaced once almost every month, which is troublesome for us and also has a certain impact on profits. PVC Polyvinyl Chloride Temperature -10℃-55℃

UPVC Unplasticized Polyvinyl Chloride Temperature -10 °C~70 °C

CPVC Chlorinated Polyvinyl Chloride Temperature -40 °C~95 °C

RPP Reinforced Polypropylene Temperature -20 °C~90 °C

PVDF Polyvinylidene Fluoride Temperature 40 °C~140 °C
