Pellet Automatic Compacting and Pelletizing Unit
Plastic Machinery-Bottle Blow Molding Machine-Fully Automatic Bottle Blow Molding Machine
Expand
Product Content
Category
Plastic Machinery-Bottle Blow Molding Machine-Fully Automatic Bottle Blow Molding Machine
Series
塑料造粒机
  • 1. Suitable for recycling and pelletizing of various films, woven bags, and non-woven fabrics such as PE, PP, etc.

  • 2. The belt feeding between the agglomerator is controlled by PLC, which can automatically control the feeding speed in segments based on the current of the agglomerator.

  • 3. The agglomerator is equipped with individual temperature control and uses a fan for forced cooling.

  • 4. The entire line has a compact structure, easy operation, and stable performance.


Single-stage Agglomeration Pelletizing

ModelMain Motor PowerAgglomerator PowerOutputL/D Ratio Range
SJ10090kW/110kW55kW300kg/H-380kg/H36:1
SJ125160kW/185kW90kW/110kW500kg/H-650kg/H36:1
SJ150185kW/220kW90kW/110kW550kg/h-700kg/H36:1
SJ160250kW/280kW132kW850kg/H-1000kg/H36:1
SJ180280kW/315kW132kW/160kW1000kg/H-1300kg/H36:1


Two-stage Agglomeration Pelletizing

ModelMain Motor PowerAgglomerator PowerOutputL/D Ratio Range
SJ100+SJ12090kW/110kW+30kW55kW300kg/H-380kg/H36:1/10:1
SJ125+SJ150160kW/185kW+37kW90kW/110kW500kg/H-650kg/H36:1/10:1
SJ150+SJ180185kW/220kW+55kW90kW/110kW550kg/h-700kg/H36:1/10:1
SJ160+SJ200250kW/280kW+90kW132kW850kg/H-1000kg/H36:1/10:1
SJ180+SJ200280kW/315kW+110kW132kW/160kW1000kg/H-1300kg/H36:1/10:1
