PA66 FR50-NC010 Enhanced Grade by DuPont, USA

¥ 50000.00/Ton
Engineering Plastic-PA-PA66
Expand

Product Content

Category
Engineering Plastic-PA-PA66
Colour
Color Categories
Plastic grades
FR50-NC010
| Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | Density | | ASTM D792/ISO 1183 | 1.6 | | | Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | Shrinkage Rate | Lateral flow | ISO 294-4 | 0.80 | % | | Shrinkage Rate | Flow | ISO 294-4 | 0.30 | % | | Water Absorption | 24 hr, 23°C, 2.00 mm | ISO 62 | 0.60 | % | | Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | Tensile Modulus | | ISO 527-2 | 10200 | MPa | | Tensile Stress | Break | ISO 527-2 | 170 | MPa | | Tensile Strain | Break | ISO 527-2 | 2.6 | % | | Tensile Modulus | | ASTM D638/ISO 527 | 10600 | kg/cm² (MPa) [psi] | | Flexural Modulus | | ASTM D790/ISO 178 | 9450 | kg·cm/cm (J/m) ft·lb/in | | Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | Heat Deflection Temperature | 1.8 MPa, unannealed | ISO 75-2/A | 240 | °C | | Melting Temperature | | ISO 11357-3 | 262 | °C | | Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | Surface Resistivity | | IEC 62631-3-2 | -- | ohms | | Volume Resistivity | | IEC 62631-3-1 | > 1.0E+13 | ohm·m | | Dielectric Strength | 2.00 mm | IEC 60243-1 | 24 | kV/mm | | Comparative Tracking Index | | IEC 60112 | 275 | V | | Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | Drying Temperature | | | 80 | °C | | Drying Time - Hot Air Dryer | | | 2.0 to 4.0 | hr | | Recommended Maximum Moisture Content | | | 0.20 | % | | Processing (Melt) Temperature | | | 280 to 300 | °C | | Optimum Melt Temperature | | | 290 | °C | | Mold Temperature | | | 70 to 120 | °C | | Optimum Mold Temperature | | | 100 | °C | | Holding Pressure | | | 50.0 to 100 | MPa | | Holding Pressure Time | | | 3.00 | s/mm | | Maximum Screw Tangential Speed | | | 12 | m/min | | Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | Charpy Impact Strength (Notched) | -40°C | ISO 179/1eU | 50 | kJ/m² | | Charpy Impact Strength (Notched) | -30°C | ISO 179/1eU | 50 | kJ/m² | | Charpy Impact Strength (Notched) | 23°C | ISO 179/1eU | 60 | kJ/m² | | Charpy Impact Strength (Unnotched) | -40°C | ISO 179/1eA | 12 | kJ/m² | | Charpy Impact Strength (Unnotched) | -30°C | ISO 179/1eA | 12 | kJ/m² | | Charpy Impact Strength (Unnotched) | 23°C | ISO 179/1eA | 12 | kJ/m² | | Property | Test Conditions | Test Method | Test Result | Unit | | --- | --- | --- | --- | --- | | UL Flammability Rating | 0.75 mm | UL 94, IEC 60695-11-10, -20 | V-0 | | | UL Flammability Rating | 1.5 mm | UL 94, IEC 60695-11-10, -20 | V-0 5VA | |
Product Consultation
Supplier
Dongguan Xianghang Plastic Technology Co., Ltd.
location
China GuangdongProvince
Main products
PC PC/ABS PCTG PA66 POM PMMA PPSU PPS
About Us
Dongguan Xianghang Plastic Technology Co., Ltd. is a company with years of experience in the research and development of various engineering plastics and specialty-grade materials. Currently, we collaborate with agents such as DuPont, Polyplastics, Sabic Innovative Plastics, DSM, Sumitomo Chemical, Teijin, LG Chem, Bayer, BASF, Hoechst, Lanxess, RTP Company, Asahi Kasei, Idemitsu Kosan, Mitsubishi Chemical, Sumitomo Chemical, Linde, Chi Mei Corporation, Degussa, Arkema, Chi Mei Corporation, and Polyplastics, among others. The engineering materials we handle include PC, PC/ABS, POM, PMMA, PCTG, PETG, PBT, PA6, PA66. Specialty engineering materials include PPS, PPSU, LCP, COC, PEEK, PA9T, PA46, PA12, POK, PEI, PPO, PPE, PFA, PSU, PTFE, PA6T, PVDF. We also provide thermoplastic elastomers such as TPU, TPE, TPR, TPEE, TPV, SBS, TPO, POP, and biodegradable plastics like PLA, PBAT, PSM, PBS, PVA. We consistently adhere to the principle "Customer is God, Integrity is Paramount" and have established our own brand within the industry. All products sold by our company are guaranteed to be of high quality and original packaging. We offer free material property sheets, SGS, UL, MSDS, RoHS, and other relevant documentation for all plastic raw materials. We firmly believe that excellent service and customer satisfaction are the foundation of success for both our company and our clients. Looking forward to a pleasant collaboration! If a type is , it does not need to be translated.
