Outdoor Rubber Cable Protector 2-Channel Rubber Cable Protector 3-Channel Rubber Cable Protector
Product Name: Cable Bridge Plate (Rubber Cable Bridge, Rubber Wiring Bridge)
Material: High-strength Rubber Base + PVC Cover Plate
Installation Steps:
1. Lay the dedicated cable channel along the specified route.
2. Open the top cover and place the dedicated cable into the channel.
3. Close the cover, and vehicles can pass freely.
Our company has developed a series of cable channel products to date:
Type A Flat Plates:
Medium Double Channel Specifications: 1000*450*70mm Channel Diameter: 50*50mm Weight: 13 kg
Double Channel Specifications: 800*300*45mm Channel Diameter: 30*25mm Weight: 7 kg
Medium Double Channel Specifications: 800*430*65mm Channel Diameter: 50*50mm Weight: 12.5 kg
Large Double Channel Specifications: 660*580*105mm Channel Diameter: 90*90mm Weight: 19 kg
Triple Channel Specifications: 1000*345*50mm Channel Diameter: 30*30mm Weight: 12 kg
Triple Channel Specifications: 800*430*50mm Channel Diameter: 30*30mm Weight: 12 kg
Large Triple Channel Specifications: 800*520*85mm Channel Diameter: 65*65mm Weight: 14.5 kg
Quadruple Channel Specifications: 800*500*65mm Channel Diameter: 50*50mm Weight: 16.5 kg
Quintuple Channel Specifications: 800*500*50mm Channel Diameter: 30*30mm Weight: 12.5 kg
Outdoor Rubber Cable Protector 2-Channel Rubber Cable Protector 3-Channel Rubber Cable Protector
All Type A flat plates can be equipped with 90° corners and three-way corners.
Type B Flat Plates:
3-Channel 1000mm*310mm*55mm (3 channels) Hole Diameter: 35x35mm
3-Channel 900mm*500mm*75mm (3 channels) Hole Diameter: 55x65mm
4-Channel 770mm*485mm*65mm (4 channels) Hole Diameter: 40x40mm
5-Channel 900mm*500mm*50mm (5 channels) Hole Diameter: 32x35mm
2-Channel 900mm*620mm*100mm (2 channels) Hole Diameter: 80x90mm
