Online Automatic Trace Hydrocarbon Chromatograph Overview

Online Automatic Trace Hydrocarbon Chromatograph Overview:
The GS-101A online automatic trace hydrocarbon chromatograph can continuously and automatically perform quantitative analysis of trace hydrocarbons in liquid oxygen, carbon dioxide, and other inert gases. It connects directly to production equipment, allowing for real-time monitoring of component concentration changes, providing essential data for the safe operation of the main condenser in air separation equipment. It can also serve as a process control instrument for detecting hydrocarbons in industries such as petroleum, chemical, steel, and gas, achieving high separation efficiency for difficult-to-separate substances (C1~C4) and high detection sensitivity (acetylene: 0.01 ppm), meeting relevant national standards. It automatically samples, injects, and outputs analysis reports. It features three-way automatic detection of liquid air/liquid oxygen/product oxygen, but can also perform single-channel detection. It has been widely applied in air separation oxygen production.

Performance Features of the Online Automatic Trace Hydrocarbon Chromatograph:
★ Automatic sampling and injection, capable of multi-point (2-8) cyclic detection, as well as single-point detection, with the possibility of unmanned operation.
★ Long service life of the dedicated chromatographic column, with a short analysis cycle (less than 5 minutes for each detection).
★ High detector sensitivity and low noise.
★ Innovative structure of the automatic sampling valve, with a long service life (up to 100,000 cycles without damage).
★ Intelligent temperature control instrument regulates the temperature, with alarms and automatic power-off protection for any channel exceeding the temperature limit.

Technical Specifications of the Online Automatic Trace Hydrocarbon Chromatograph:
★ System stabilization time: <1.0 hour
★ Temperature control accuracy: ±0.1℃
★ Temperature control range: RT + 5~350℃
★ Baseline drift ≤1×10-11A/30min
★ Baseline noise ≤1×10-12A
