Scope of Application
System
This product is suitable for power transmission in AC circuits with a frequency of 50Hz and a rated voltage of 0.6/1kV (system voltage is 1.2kV).
Occasions
Widely used in nuclear power plants, subway stations, telephone exchanges, computer control centers, high-rise buildings, hotels, broadcasting stations, important military facilities, oil platforms, and other places with high population density and low air density.
Product Features
This product has excellent flame retardant properties, producing very little smoke during combustion, and does not emit corrosive gases.
Compliance Standards
Cable Specification Number
ZL45TM005737.1-2014【WDZCN-YJE 0.6/1kV】
Implementing Standard
GB/T 12706.1-2008 Rated voltage 1kV (Um=1.2kV) to 3kV (Um=3.6kV)
Additional Standards
GB/T 19666-2005 General rules for flame retardant and fire-resistant wires and cables
Usage Characteristics
Rated Voltage
The rated voltage for AC power frequency is 0.6/1kV, and the operating voltage of the AC system should not exceed 1.2kV.
Working Temperature
The long-term allowable working temperature of the cable conductor is 90℃; during a short circuit, the temperature of the cable conductor should not exceed 250℃, and the duration should not exceed 5S.
Ambient Temperature
The operational ambient temperature of the cable is -10℃.
Laying Temperature
During installation, the temperature should not be lower than 0℃.
Bending Radius
The recommended minimum bending radius for unarmored single-core cables during installation is 20D. For armored single-core cables, it is 15D. For armored three-core cables, it is 12D, and for unarmored three-core cables, it is 15D.
