LHDZ-0713 Uniaxial Compression Testing Machine for Asphalt Mixtures
Uniaxial Compression Dynamic Modulus Testing Machine for Asphalt Mixtures
The Uniaxial Compression Dynamic Modulus Testing Machine for Asphalt Mixtures is developed and produced according to the experimental requirements of JTG E20-2011 "Test Regulations for Asphalt and Asphalt Mixtures in Highway Engineering".
Main features of the Uniaxial Compression Testing Machine for Asphalt Mixtures:
1. Equipped with overload protection and descent position protection.
Crude Oil Water Content Determination Instrument ML204 Variable Speed Multi-Purpose Oscillator
2. Easy to operate, accurate test data, stable and reliable performance.
3. The instrument conducts automatic testing, displays and prints test pressure and corresponding flow values, and plots the coordinate curve of the specimen's stress and deformation.
4. Capable of storing test results for 15 specimens.
5. Large LCD screen display.
6. Flow value detection has both single-channel and dual-channel options.
7. Testing is automatically controlled by the instrument or computer, and the data and curves of the specimen's compression deformation process are automatically saved and displayed by the computer, which can be printed out using a color inkjet printer.
Class 100 Laminar Flow Room Plastic Bending Testing Machine Woven Bag Tensile Testing Machine
8. The machine is equipped with a USB interface.
9. Optional serial port, and the upper computer software can perform analysis and processing.
Main technical specifications of the Uniaxial Compression Testing Machine for Asphalt Mixtures:
1. Rising rate: (50±5) mm/min
2. Piston diameter: (102±0.2) mm
Tapered Twist Drill Photochemical Reaction Instrument Vertical Flow Purification Workbench
3. Maximum pressure: 50 KN, Accuracy 1%
4. Flow value range: 0-15.00 mm, Accuracy ±0.1 mm
5. Ambient temperature: ≤30℃.
6. Relative humidity: ≤85%.
7. Total power consumption: Not exceeding 700W.
8. Dimensions: 70x50x90 mm
9. Net weight of the instrument: 100 kg
10. Power supply voltage: 220V
