KYH-MLN-2 Type Marsh Funnel Viscometer (with plastic cup)
1. Purpose and Features
The KYH-MLN type Marsh Funnel Viscometer is an instrument used for daily measurement of drilling fluid relative viscosity (compared to water). Manufactured according to the American API standard, the viscosity of the drilling fluid is determined by the time it takes for 946ml of drilling fluid to flow out of the funnel.Piston cut-off valve Combined air blower unit Extended taper handle twist drill Dry well furnace Geotextile tensile testing machine
Since the measured data is greatly affected by colloid content and specific gravity, this instrument cannot be directly compared with the data measured by rotational viscometers, shear forces, and rheometers.Plastic bending test machine Rubber product tensile testing machine Environmental protection electric heating sleeve
This instrument is easy to carry, easy to operate, and widely used in petroleum, geological exploration, and other departments, especially suitable for daily measurement of drilling fluid viscosity in field drilling sites.
2. Model and Specifications
KYH-MLN-2/KYH-MLN-3/KYH-MLN-4
1 Configuration: With plastic cup, with stainless steel cup, with stainless steel cup and stopwatch.
2 Screen mesh aperture: 1.6mm (12 mesh)
3 Capacity below the funnel bottom: 1500ml
4 Accuracy: When injecting 1500ml of distilled water into the funnel, the time for 946ml of distilled water to flow out is 26 ± 0.5s 1. Purpose and Features
The KYH-MLN type Marsh Funnel Viscometer is an instrument used for daily measurement of drilling fluid relative viscosity (compared to water). Manufactured according to the American API standard, the viscosity of the drilling fluid is determined by the time it takes for 946ml of drilling fluid to flow out of the funnel.Lightning protection component tester Taper handle twist drill Maintenance-free energy-saving lamp Speed-adjustable multi-purpose oscillator Crude oil water content rapid determination instrument Fresh noodle production line
Since the measured data is greatly affected by colloid content and specific gravity, this instrument cannot be directly compared with the data measured by rotational viscometers, shear forces, and rheometers.Mettler PH meter LMI Milton Roy CNC lathe milling compound center
This instrument is easy to carry, easy to operate, and widely used in petroleum, geological exploration, and other departments, especially suitable for daily measurement of drilling fluid viscosity in field drilling sites.
