Guangzhou Zhunli Technology Co., Ltd.✆ 13539761159☎ 020-62208903 Advantages Long-term direct supply TKD-KABEL KAWEFLEX 5340 TKD towline cable, E212916 UL/CSA AWM 21198 AWM I/II A/B 300V/80°C FT2 KAWEFLEX 5340 TKD-8X2X0,25 CE E6 ZL68061 high-flexible towline shielded cable, UL / CSA standard, decoupling circuit through twisted pair, preventing electromagnetic induction, decoupling through twisted pair. Halogen-free flame retardant and low adhesion special grease. Comply with RoHS standards, long service life, conductors in accordance with DIN VDE 0295-6. IEC 60228-6 standard thin steel wire core wire colored according to DIN 47100 standard PELON insulation, special PUR outer sheath, RAL 7001 silver gray/RAL 2003 orange. Rated voltage 300 V, test voltage 1500 V. Dynamic installation temperature -30°C / +80°C, flame retardant standard complies with VDE 0482-332-2-1 or DIN EN 60332-2-1, 80°C, UL 80°C, 300 V, cULus 80°C, 300 V; Advantages are applied in mechanical engineering, high electrical data and signal transmission, automation industry, communication technology, computer technology, chemical industry, measurement and control technology, mechanical towline requirements, rotary equipment, robot processing automation electrical installation. The bending radius is only 7.5 times the cable diameter. The following is the detailed material model specifications for the data transmission cable for TKD-KABEL KAWEFLEX 5340 TKD towline:
TKD-KABEL KAWEFLEX 5340 TKD silver gray outer sheath KAWEFLEX 5340 SK-TP-C-PUR UL/CSA1504435 KAWEFLEX 5340 TKD-2X2X0,25
1504436 KAWEFLEX 5340 TKD-3X2X0,25
1504437 KAWEFLEX 5340 TKD-4X2X0,25
1504438 KAWEFLEX 5340 TKD-6X2X0,25
1504439 KAWEFLEX 5340 TKD-8X2X0,25
1504442 KAWEFLEX 5340 TKD-10X2X0,25
1504440 KAWEFLEX 5340 TKD-12X2X0,25
1504443 KAWEFLEX 5340 TKD-16X2X0,25
1504441 KAWEFLEX 5340 TKD-21X2X0,25
1504444 KAWEFLEX 5340 TKD-30X2X0,25
1504469 KAWEFLEX 5340 TKD-2X2X0,34
1504470 KAWEFLEX 5340 TKD-3X2X0,34
1504471 KAWEFLEX 5340 TKD-4X2X0,34
1504472 KAWEFLEX 5340 TKD-6X2X0,34
1504473 KAWEFLEX 5340 TKD-8X2X0,34
1504474 KAWEFLEX 5340 TKD-10X2X0,34
1504475 KAWEFLEX 5340 TKD-14X2X0,34
1504445 KAWEFLEX 5340 TKD-2X2X0,5
1504446 KAWEFLEX 5340 TKD-3X2X0,5
1504447 KAWEFLEX 5340 TKD-4X2X0,5
1504449 KAWEFLEX 5340 TKD-6X2X0,5
1504451 KAWEFLEX 5340 TKD-8X2X0,5
1504453 KAWE...> WYBLYK
