Product Composition: Salt Tank, Electrolytic Cell, Cooling System, Intelligent Electrolytic Power Supply, Control System, Safety Protection System
Reaction Principle: 2NaCl + 3H2O → ClO2 + 2NaOH + 2H2
Raw Material: Industrial Salt GB/T54622003 Refined Industrial Salt ≥ 99.10%
Equipment Working Principle: ICU Ward Purification Project Heat Deformation Vicat Tester
The equipment uses the electrolysis of sodium chloride to produce chlorine dioxide as a synergistic disinfectant, consuming only sodium chloride and water as raw materials. The intelligent constant current electrolytic power supply converts AC power into DC power with a voltage not exceeding 12 volts (safe voltage). In the electrolytic cell equipped with special electrode plates and electrolytic membranes, saturated sodium chloride aqueous solution is electrolyzed to generate chlorine dioxide synergistic disinfectant. The disinfectant dosing system automatically injects the chlorine dioxide synergistic disinfectant produced by the equipment into the water to be disinfected, achieving the purpose of disinfection treatment.
Performance Characteristics: Woven Bag Tensile Tester Magnetic Stirring Electric Heating Mantle Mettler pH Meter
The titanium-based anode is made of a coating of ruthenium, iridium, rhodium, and platinum, with stable performance, high electrolysis efficiency, no cleaning required, and corrosion resistance.
The asymmetrical corrosion-resistant electrolytic membrane, developed and produced from imported raw materials, features high conductivity, corrosion resistance, micropore size, and maintenance-free characteristics.
This electrolytic membrane not only enhances the efficiency of the disinfectant production but also reduces salt and electricity consumption.
The scientifically designed pure titanium heat exchange system keeps the equipment at the working temperature and has good heat dissipation performance, saving cooling water.
Solid salt can be directly added, making it safe and convenient, avoiding the hassle of preparing saturated brine.Tapered Handle Twist Drill High-Pressure Reaction Kettle High-Pressure Sterilizer
The generator is fully sealed in design, with no leakage of electrolytic liquid or disinfectant during operation.
The electrolytic power supply adopts an intelligent constant current design, capable of accepting external passive switch signals to control start and stop. The operational status of the electrolytic power supply can be remotely displayed through the RS485 communication port. The electrolytic power supply can receive external 4-20mA analog signals for PID control of the chlorine dioxide synergistic disinfectant generation amount, which can be combined with a flow meter or online chlorine residual sensor for automatic feedback control, ensuring that the disinfectant concentration in the treated water is always maintained within the set range. Speed Adjustable Multi-purpose Oscillator
